Qizhi CNC Four-Roller Plate Rolling Machine

Product Description

QIZHI CNC four-roller plate rolling machine This machine is a fully automatic hydraulic four-roller plate rolling machine, which is used to roll the steel plate into a cylindrical shape at room temperature. The upper roller is fixed; the lower roller and both side rollers can move up and down. The upper roller is the main driving roller, which provides torque for sheet rolling through its rotation. The rollers on both sides are driven rollers. Pre-bending is achieved by clamping the sheet with the upper and lower rollers, and lifting and lowering the side rollers to deform the sheet. When rolling, the hydraulic motor planetary reducer drives the driving roller to rotate.
Specifications

Model	Max. rolling thickness	Max. pre-rolling thickness	Plate width	Diameter of upper roller	Main motor power
	(mm)	(mm)	(mm)	(mm)	(kw)
W12CNC 6x1500	6	4	1500	220	4
W12CNC 8x1500	8	6	1500	240	5.5
W12CNC 8x2000	8	6	2000	280	5.5
W12CNC 8x2500	8	6	2500	260	7.5
W12CNC 10x2000	10	8	2000	280	7.5
W12CNC 12x2500	12	8	2500	320	7.5
W12CNC 16x2500	16	12	2500	350	15
W12CNC 20x2000	20	16	2000	350	15
W12CNC 20x2500	20	16	2500	350	18.5
W12CNC 25x2000	25	20	2000	350	18.5
W12CNC 25x2500	25	20	2500	400	18.5
W12CNC 30x2000	30	25	2000	400	18.5
W12CNC 30x2500	30	25	2500	420	22
W12CNC 30x3000	30	25	3000	470	30
W12CNC 40x3000	40	32	3000	550	37
W12CNC 50x3000	50	40	3000	610	45
W12CNC 60x3000	60	50	3000	670	55
W12CNC 70x3000	70	50	3000	730	75
W12CNC 80x3000	80	70	3000	780	90
W12CNC 90x3000	90	80	3000	820	90
W12CNC 100x3000	100	90	3000	880	110

This machine can be customized based on user's requirements. Pressure Vessel Fabrication

---
