US$590.00-1,590.00
|
1 Piece
(MOQ)
|
Basic Info.
Processing Object
Cereals
Processing Technics
Crushing-before-Mixing
Screen Mesh
With Screen Mesh
Grinding Equipment Type
Feed Hammer Mill
Pellet Mill Type
Flat Die Pelletizer
Bulking Machine Type
Twin Screw Bulking Machine
Expanding Method
Dry Expansion
Applicable Materials Shape
Short strip
Warranty
2 Years Guarantee
Key Word 1
Flat Die Pellet Machine
Key Word 2
Wood Pellet Mill
Transport Package
Wooden Cases
Specification
650*300*600mm
Production Capacity
100000
Product Description
75kg Capacity Flat Die Poultry Chicken Hen Duck Goose Bird Fish Feed Pellet Machine
Raw Material:
The materials such as the rice husk, sunflower husk, peanut shell and other fruit shell; branch, trunk, bark and other wood waste; a variety of crop straws; rubber; cement, ash and other chemical materials.
Product introduction:
1. The flat die pellet machine is mainly used for the pressing of animal feed.
2.The device is light,easy tomove
3.ldeal choice for users of homes and small-scale farms
4.The compressed pellet is healthier for poultry and livestock, such as chicken, duck,fish,pig,cattle etc.
Technical details:
Pelletizing is the process of making waste materials into solid fuel. Wood pellet can be made from any type of Agro-Forestry waste: Groudnut-shell, Sugarcane Biogases,Caster Shells/Stalk, Sawdust,Coffee Husk,Peddy Straw, Sunflower Stalk, Cotton Stalks, Cotton Stalks, Tobacco waste, Mustard Stalk, Jute Waste, Bamboo Dust, Tea waste, Wheat Straw, Palm husk, Soybeans husk, Coir Pitch Barks/Straws, Rice Husks, Forestry waste, Wood Chips and many other Agro wastes. But the content should be less than 12%, grain size is below 5*5mm.
Questions beofre sending price list:
1.What's your raw materials ?
Corn , Wheat or Soybean ,with grass
2. Please send us your raw materials photo.
We will confirm whether need to crusher machine
3. Capacity Per Hour you want to ?
We have 80-100kg/h , 100-300kg/h , 300-500kg , 500-700kg/h , larger 1000kg
4. Your voltage ?
380V ,50HZ, 3Phase or others ? we will design the suitable motor for you .
5.How much the mositure of your raw material?
10%-20%,20%-30%,30%-40%,or others ?
Model plate:
The diameter of the finished pellet are depends on the diameter of the model plate hole, and we can offer the diameter from 2.5m-8mm.The Model plate is easy to change. You can get different size(2.5-8mm) pellet with one machine.
Technical information:
| Model | Power puissance | Capacity(feed)(kg/h) | Capacity(fuel)(kg/h) | Weight(kg) | Size(mm) |
| WSKL-125 | 2.2kw-3kw | 75-100 | 40-60 | 75kg | 650*300*600mm |
| WSKL-150 | 3kw | 90-120 | 70-80 | 95kg | 750*400*820mm |
| WSKL-200 | 7.5kw | 200-300 | 100-150 | 110kg | 900*400*750mm |
| WSKL-230 | 11kw | 300-400 | 200-300 | 150kg | 1180*580*880mm |
| WSKL-260 | 15kw | 400-600 | 300-400 | 135kg | 1200*500*1070mm |
| WSKL-300 | 22kw | 600-800 | 500-600 | 220kg | 1250*520*1070mm |
| WSKL-360 | 22kw | 800-900 | 700-800 | 350kg | 1270*520*1070mm |
| WSKL-400 | 30kw | 1000-1200 | 800-1000 | 600kg | 1470*500*1150mm |
Advantages:
Power :You can choose the gasoline engine driven, diesel engine driven,electric motor driven or PTO system for engine.
Quality:The machine adopts speed-adjust feeder to control the feeding capacity, and use big diameter modulator to make materials fully cured, and make the pellet smoother.The formation rate reaches 98%
Model:The Model plate is easy to change. You can get different size(2.5-8mm) pellet with one machine.
Final Pellet: This machine can both produce fuel and feed.
>>
