Metal Drilling Equipment BTA CNC Deep Hole Drilling Machine Dh-1600

Product Description

Drilling is universally acknowledged as the bedrock of machining operations, integral to a multitude of applications. Traditional drilling equipment, such as bench drills, milling machines, and radial drills, have historically necessitated manual labor, anchoring workers to repetitive tasks with restricted quality assurance. This has been compounded by challenges regarding safety, efficiency, and processing constraints, presenting significant obstacles for manufacturers and operators. However, with the emergence of the CNC era, the innovative CNC deep hole drill has revolutionized the industry, emancipating laborers from manual restrictions and overcoming deep drilling challenges. This cutting-edge technology allows for single-pass drilling that rivals the quality of conventional machines, while also executing reaming and expanding processes. Moreover, it automates chip removal, CNC positioning, and processing with precision, redefining efficiency and significantly enhancing output quality in the industry.

3 Axis CNC Deep Hole Drilling Machine	4 Axis Vertical CNC Deep Hole Drilling Machine	Multi-Spindle CNC Deep Hole Drilling Machine	6 Axis CNC Deep Hole Drilling Machine

The precision-engineered CNC deep hole drilling machine by Shenzhen Joint Machinery Co., Ltd. is meticulously crafted to accommodate a wide array of workpieces requiring advanced deep hole processing:
√ Die & Mould Industry: Exceptionally suited for intricate operations such as creating water transport holes, center holes, hot runners, guide roller holes, and more, ensuring precision and excellence.
√ Auto Industry: Perfectly designed for intricate deep hole processing within cylinder heads, crankshafts, hydraulic tubing, plunger bushings, and more, delivering exceptional performance and precision.
√ Oil Pump & Lubricating Nipple Industry: Expertly tailored for deep hole drilling in oil-injection gases, nozzle valves, plunger bushings, and a wide range of critical spare parts, ensuring top-tier reliability.
√ Textile Machinery Industry: Achieves precision mesopore drilling across various spindles with ease, enhancing productivity and quality.
√ Medical Equipment Industry: Specializes in axial processing on robust materials like titanium alloys and stainless steel, meeting the meticulous and stringent standards required by the medical industry.
√ Mining & Oil Machinery: Provides robust solutions for deep hole processing on piston rods and cylinder walls, tailored to accommodate the rigorous demands of heavy-duty applications.
√ Electrical Power & Steam Turbine Industry: Excels in deep hole processing of rotors, central spindles, valve spindles, unit outer cylinders, and condenser tube plates, ensuring enhanced performance and reliability.
Metal Drilling Equipment BTA CNC Deep Hole Drilling Machine DH-1600

Model	Unit	DH-1600
Inner diameter of drilling	mm	2.5-35
Max depth of drilling	mm	1600
Table size	mm	1800*1150
X axis travel	mm	1600
Y axis travel	mm	1100
Z axis travel	mm	1600
Cutting feeding	mm/min	1-300
Max rotary speed of spindle	rpm	7000
Spindle motor	kw	7.5/11
Three axis motor	kw	4.4/4.4/2.3
Pressure of oil pump	kg/cm	0-150
Capacity of cutting tank	L	800
Max load weight of table	kg	13000
Weight	kg	14000
Dimension	mm	5500*4300*2800

Shenzhen Joint Machinery Co., Ltd. stands as a paragon of excellence, specializing in the production and export of CNC lathe machines, CNC deep hole drilling machines, Swiss-type automatic lathes, milling machines, grinding machines, and more. Our unwavering commitment to unparalleled quality and service forms the cornerstone of our operations, ensuring that every machine meets the highest industry standards. By integrating cutting-edge technologies from Taiwan and Germany, our production processes employ state-of-the-art equipment to deliver machines renowned for their precision, stability, and reliability. Designed to meet complex, high-demand machining needs, our products have earned international acclaim and a devoted customer base spanning Asia, Europe, South America, and North America. Through dedicated partnerships with clients globally, we create significant business value, together shaping the future of the industry.
