| VIDEO | |
| Video standard | PAL; NTSC |
| Video compression | H.264 |
| Video resolution | 4MP/3MP/1080p/960p/720p/D1/4CIF/DCIF/2CIF/CIF/QCIF |
| Video input | 8CH*3MP(BNC)@4main Play 4CH*4MP(BNC1,3,5,7)@4main Play 8CH*3MP(BNC)+8CH*3MP(IPC)@8Sub-Play/1main Play 4CH*4MP(BNC1,3,5,7)+4CH*4MP(IPC)@4Sub-Play/1main Play |
| Video output | VGA/HDMI sync output:1920×1080P@60Hz,1440×900P@60Hz, 1366×768P@60Hz, 1280×1024P@60Hz,1024×768P@60Hz,800×600P@60Hz |
| Video bit rate | Self-Define(16-8000Kbps) |
| Image display | 1/4/6/8/9/16/20/25/36 |
| Snapshoot | Support (JPEG) |
| Motion detection | 396 (22*18) surveyed area can be set in every screen and multi-sensitivity adjustable |
| AUDIO | |
| Audio encoding | G.711A |
| Audio input | 4CH |
| Audio output | 1CH |
| Bidirectional talk | / |
| RECORDING& PLAYBACK | |
| Video frame rate | 8CH mode: 3MP@10fps;1080P@15fps, analog/IPC@25fps(PAL) /30fps(NTSC) real-time; 4CH mode: 4MP@15fps,3MP@10fps,1080P@25fps(PAL)/30fps(NTSC)real-time, analog/IPC@25fps(PAL)/30fps(NTSC) real-time. |
| Record mode | Manual/ Timing MD/Alarm exception/MD or alarm/MD and alarm |
| Playback synchronic | Analog 4CH/hybrid 1CH sync-playback(Main stream) 4CH/8CH sync-playback(Sub stream) |
| Search method | Time, Calendar, Event, Channel |
| Video playback | Start, Stop, Fast play, Slow play, Frame play, Snapshoot, Full screen, Roller amplification time ball precise playback |
| VIDEO BACKUP | |
| Interface | 2 SATA |
| HDD capacity | Single Max. 6T |
| Backup location | Local HDD, Network |
| Backup method | Network,USB storage device,USB recorder |
| NETWORK | |
| Protocol | TCP/IP, HTTP, DDNS, SMTP(SSL), DHCP, PPPOE, UPNP, NTP, P2P, Onvif |
| EXT INTERFACE | |
| video input | 8CH BNC port(1.0Vp-p,75Ω) |
| Network interface | RJ45 10M/100M/1000M self-adptive Ethernet port |
| Alarm input | 8CH |
| Alarm output | 3CH |
| RS-485 interface | 1 RS485 port |
| USB port | 2 USB2.0 |
| e-SATA | / |
| GENERAL | |
| Temperature | -10°C ~ 55°C/10%-90% |
| Power supply | DC12V/5A |
| Power consumption | 35W (Without HDD) |
| Unit dimension(mm) | 360(L)* 262(W)*48(H ) |
| Weight | 1.5 Kg |
