Reclaimed Rubber Making Machine/Rubber Dynamic Devulcanizer

Product Description

Parameter Content	Model
	ZT-3.3R		ZT-4.5R	ZT-6R		ZT-8R
Design Pressure	2.1Mpa		2.1Mpa	2.1Mpa		2.1Mpa
Working Pressure	1.8Mpa		1.8Mpa	1.8Mpa		1.8Mpa
Design Temperature	3000C		300 0 C	300 0 C		300 0 C
Working Temperature	2090C		209 0 C	209 0 C		209 0 C
Active Volume	3.0m3		4.5m3	6m3		8m3
Rotate Speed of Blender	16r/min		16r/min	15r/min		15r/min
Jacket Volume	0.72m3		1.04m3	1.6m3		1.8m3
Design Pressuer of Jacket	0.5Mpa		0.5Mpa	0.5Mpa		0.5Mpa
Working Pressure of Jacket	0.3Mpa		0.3Mpa	0.4Mpa		0.4Mpa
Heating Method	Heat conduction oil
Hear Exchange Area	8.18m2	12.55m2		15m2	17m2
Motor Power	15kw	18.5kw		18.5kw	18.5kw

Reclaimed Rubber Making Machine/rubber dynamic devulcanizer
Application
This product is used for that in order to reach even and effective desulfidation for rubber powder, put
Pulverous crosslinked rubber, softener, activator and water into the pot, heat hermetically and mix contlnuously, adopted key equipment for the technology of high temperature dynamic desulfidation.
Characteristics
This product is a horizontal pressure vessel Type II, heats up with the heat conduction oil. Customers
Could select two ways-automatic and manual operation for pot gate opening and closing. Upside of the
Pot is charge port, and downside is discharge port. Full auto-dynamic pot opening and closing gate is controlled by hydraulic pressure. Adopt manual mechanical alternate out hand opening and closingate
For the manual dynamic opening and closing gate. Above two dynamic pots are linked to the zero pressures witch to ensure safety. Adopt JZQ series reducer through douole row chain wheel rotating or direct driving for the blender, positive and negative rotating could be controlled automatically. The shape of mixing propeller is assorted of ribbon and mural. The parts of pressure vessel are designed and manufactured according to BG150-98 "Steel Pressure Vessel" and have been inspected examination and approved by. Hebei
Province Technology Inspection Office of Boiler and Pressure Vessel.

---
