| Model | TFG2922A | TFG2924A | TFG2932A | TFG2934A | TFG2942A | TFG2944A | |
| Channel | 2 | 4 | 2 | 4 | 2 | 4 | |
| Frequency | |||||||
| Sine | 1μHz~200MHz | 1μHz~30MHz | 1μHz~400MHz | ||||
| Square | 1μHz~120MHz | ||||||
| Pulse | 1μHz~80MHz | ||||||
| Ramp | 1μHz~6MHz | ||||||
| Others | 1μHz~50MHz | ||||||
| Resolution | 1μHz | ||||||
| Accuracy | ±1ppm | ||||||
| Waveform | |||||||
| Type | 165 kinds include: Sine, Square, Ramp, Pulse, Noise,DC, PRBS, bulit-in arbitrary waveforms and user-defined harmonic, etc. | ||||||
| Sample Rate | 1.2GSa/s | ||||||
| Vertical Resolution | 14 bits | ||||||
| Arbitrary | Sample Rate | 1uSa/s~200MSa/s | |||||
| Length | 2 ~ 32M points | ||||||
| Resolution | 14 bits | ||||||
| Square | Rise/Fall Time | ≤2.5ns | |||||
| Duty Cycle | 0.01％~99.99％ | ||||||
| Pulse | Rise/Fall Time | 2.5ns ~1.2s | |||||
| Width | 4ns~(1000000s ~4ns) | ||||||
| Sine Spectral Purity | |||||||
| Total Distortion | ≤0.2% (20Hz~20kHz, 20Vpp) | ||||||
| Phase Noise | <-140dBc @ 10MHz (0dBm, 10kHz offset) | ||||||
| Amplitude | |||||||
| Range (50Ω load) | f≤40MHz | 1mVpp~10Vpp | |||||
| f≤100MHz | 1mVpp~5Vpp | ||||||
| f≤200MHz | 1mVpp~2Vpp | ||||||
| f≤300MHz | 1mVpp~1.5Vpp | ||||||
| f>300MHz | 1mVpp~1Vpp | ||||||
| Accuracy | ±(1％of setting＋1mVpp), (Sine 1kHz，0V offset，≥10mVpp) | ||||||
| Offset | |||||||
| Range | ±5Vpk ac+dc (50Ω load) | ||||||
| Accuracy | ±(1%of setting+2mV+0.5% of amplitude)(High-Z) | ||||||
| Modulation | |||||||
| Type | FM, AM, PM, PWM, Sum, FSK, 4FSK, NFSK, PSK, 4PSK, NPSK,ASK, OSK | ||||||
| Burst | |||||||
| Burst Count | 1 to 100000000 | ||||||
| General Characteristic | |||||||
| Power | AC 100~240V, 45~65Hz , <70VA(TFG29X2A), <80VA(TFG29X4A) | ||||||
| Dimension & Weight | 363*154*327 mm, 7.0KGs, (TFG29X2A) | ||||||
| 363*154*467 mm, 10.0KGs, (TFG29X4A) | |||||||
