Multi-Channel Groundwater Finder Admt-200s 16D Mobile Phone Mapping 3D Underground Water Detector

Product Description

Multi-channel Groundwater Finder ADMT-200S 16D Mobile Phone Mapping 3D Underground Water Detector
How to find a good drilling point? You may rely on expericence or hiring a geologist. What if you find the wrong drilling point? Your time will be waster and so is your money. You don't have to put your time and money at risk any more! Check the best underground water detector! The underground water detector will form a geophysical map underground and you can see clearly the underground structure.
Check out the advantage of our underground water detector and get yours soon!
Based on over 40 years research and development design and exploration, the mobile phone water/metal detector realize the technology that you can use the mobile phone or tablet PC to do complex data calculation, then the graphs will automatic form, store in the cloud, and you can communicate with experts advisors on line about your graphs.
With wireless sensor, you don't have to cabling and can just measure by walk and stop, free of USB disk, detection button. Automatcally mapping by mobile phone, communicating with experts advisors online, uploading the data into cloud and store permanently.

Main Features:
1. Automatically forming the graphs: Measuring by mobile phone and automatically forming the graphs after done.
2. Free of cabling: Measuring by walk and stop , and can use wireless sensor probes to solve cabling problems.
3. Online Instant Experts communication: You can directly communicate with our online experts for advise by mobile phone APP, uploading photos in the scene, instant data, effect graphs and etc to communicate online.
4. Free of USB disk: Data is directly stored in the mobile phone, or uploading to the cloud for permanently store or download to the computer.
5. Independent Choice of Display size: The display size and capability of mobile phone or tablet PC for operating is update to your own. What size of your mobile phones or tablet PC is, what experience of display you can get (5", 6", 8", 10" etc as you have).
6. More reasonable Data Processing: Strengthen the function of "Field Source Modify" (Patent number 201310205318.9). This project also obtained over 20 patents for invention.

Specifications

Parameter	ADMT 100S	ADMT 200S	ADMT 300S	ADMT 400S	ADMT 600S	ADMT 800S	ADMT 1200S	ADMT 2000S	ADMT 3000S
Measurement Range	0-300mv
Detect Depth	0-100m	0-200m	0-300m	0-400m	0-600m	0-800m	0-1200m	0-2000m	0-300m
Measuring Mode(Intelligent frequency select)	20 frequencies	40 frequencies	60 frequencies	80 frequencies
Resolution	2mv	1mv	0.5mv	0.2mv	0.1mv	0.1mv	0.01mv
Repetitive Error	±5%±2 bit	±3%±2 bit	±2%±2 bit	±2%±2 bit	±1%±1 bit	±1%±1 bit	±1%±0.5 bit
A/D Swith	16 bit 1Msps			24 bit 1 Msps
Power frequency	>80dB
Data Storage	Mobile phone or tablet PC (touching LCD 5-10.1''
Display	Bluetooth 4.0
Mainframe Power	DC7.4V 3400mAh lithium battery			DC7.4V 6800mAh lithium battery
Mainframe Power Consumption	160mA	230mA	230mA	360mA	360mA	360mA	450mA
Operating Temperature	-10ºC-+40ºC		-20ºC-+60ºC		-40ºC-+70ºC
Mainframe Size	18.6*14.8*8cm
Mainframe Weight	0.8kg			0.9kg

FAQ Q:How is the accuracy of the water detector?
A:Up to 95%, result differs due to different situation.

Q: How is the weight of the water detector? Is it easy to carry with?
A:The water detector is 6.5kg only, light in weight, easy to carry with.

Q:Is the equipment easy to use?
A: Yes, you can learn to use it within 1 hour.

Q:What if I meet with difficulties in analyzing the graphics? Can I turn to you for help?
A: Sure! We have a professional team of geologists. We will provide lifetime person to person data analysis service for you. Whenever you need, we are always ready to help.

Company Information ABT Drilling Equipment Co., Ltd. mainly provides holistic drilling solutions, serving the mining, stone crushing, water conservancy drilling industry, to help you solve the problem of drilling at high efficiency and low cost. We mainly provide mobile air compressors, drilling rigs, hammer, drill bit, crushers, underground water detector.We are your trustworthy partner.

---
