wooden chopsticks making machine/wooden chopsticks production line

Product Description

Product Description
Product Description
Wood Chopsticks production line
Brief introduction:
Popular chopstick making machine is used for producing wooden chopsticks which is composed of 7machines.
It can use many different specifications woods, such as round log, square wood and undersized wood.
1.Process: above products prior to log into standard dry blank - shard - branch - length cut - molding - polishing - packing.
2.More than 7 units in a production line, production of 210 mm specification double chopsticks, 8 hours of 40000- 50000 pairs of production, need 3-4 employees. Use 380 v electric industry. Add double TZ-218 machines, 120000 pairs of production.
Parameter:
1.Wood Flaker:

Model	Picture	Motor	Dimension	Weight
TZ-656		5.1kw	1030*620*950mm	320kg

2.Bamboo filament set-size machine:

Model	Picture	Motor	Dimension	Weight
TZ-105		0.75kw	1500*650*990mm	85kg

3.Chopsticks forming machine:

Model	Picture	Motor	Dimension	Weight
TZ-218		4.1kw	2250*700*1400mm	600kg

4.Chopsticks mincing machine:

Model	Picture	Motor	Dimension	Weight
TZ-217		0.75kw	500*350*800mm	40kg

5.Toothpick polishing machine:

Model	Picture	Motor	Dimension	Weight
TZ-106		1.5kw	2400*1000*990mm	230kg

6.Multi-sharpen machine:

Model	Picture	Motor	Dimension	Weight
TZ-108		0.55kw	370*330*720mm	50kg

7.Chopsticks packing machine:

Model	Picture	Motor	Dimension	Weight
TZ-109		0.45kw	1500*600*1300mm	240kg

Photo show:
