| US$189.00 | 1 pieces (MOQ) |
| Products Status | Stock |
| Model Number | HZ-JL82599-F2 |
| Place of Origin | China |
| Lifecycle | Active |
| Inventory | Yes |
| control chip | Intel 82599ES |
| Optical Data Rates | 10 Gb/s |
| Ports | 2 |
| LED | Left- Activity LED: green (green on when there is no data, blinking when there is data) |
| Operating system Support | Windows10/8.1/8 Windows Server2019/2016/2012/2008/2003 Linux |
| Operating Humidity | 0%-85%, non-condensing |
| Operating Temperature | 0°C to 45°C |
| Storage Temperature | -20°C to 75°C |
| lead-free technology | RoHS-R6 |
| OS Support | Additional support is available from OEMs and partners, Linux, Solaris, VMware vSphere, Windows Hyper-V, Windows Server |
| Power Supply | 1.8V, 1.2V, 0.9V |
| Industry Standards | Current ANSI/IETF Standards: FC-PI-4, FC-AL, FC-AL-2 with amendments 1 and 2, FC-DA, FC-FLA, FC-FS, FC-FS-2 with amendment 1, FC-GS-2/3/4/5, FC-GS-6, FC-HBA, FC-LS-2, FC-MI, FC-MJS, FC-PH-2, FC-PH-3, FC-PI, FC-PI-2, FC-PI-5, FC-PLDA, FC-SB-2, FC-SB-4, FC-SP, FC-SP-2, FC-TAPE, FCP, FCP-2, FCP-4, Fibre Channel class 2 and 3, Legacy ANSI/IETF standards: FC-PH, PCIe base spec 3.0, PCIe card electromechanical spec 3.0, PHP hot plug-hot swap, RFC2625, RFC4338, SBC-2, SBC-3, SPC-3, SPC-4, SSC-2, SSC-3 |
| Whats in the box | In an effort to reduce excessive packaging, each Host Bus Adapter (HBA) ships in a small, space-efficient box. Drivers, installation manual and firmware updates are downloadable from . Each box includes: · Quantity 1, low-profile Host Bus Adapter with fixed optics · Quantity 1, full-height bracket · Quantity 1, low-profile bracket · Quantity 1, Firmware download sheet and RoHS sheet |
| Cable Support | 50/125μm (2000MHz*km BW)-up to 150m, 50/125μm (500MHz*km BW)-up to 50m |
| Data Transfer Rates | Supports 8GFC, 4GFC and 2GFC link speeds, automatically negotiated |
| Hardware Environmen | PowerPC, SPARC, x86, x64 and Intel Itanium 64-bit processor family |
| I/O Controller | XE201 |
| Regulatory Certifications | AS/NZS CISPR:2009 +A1, Class A, Australian EMC Framework (RCM), BSMI Class A, CNS13438:2006 (complete), China RoHS Compliant, EMC Directive 2004/108/EC (CE Mark), EN55022:2010, Class A, EN55024:2010, EU RoHS Compliant (Directive 2011/65/EU), FCC Part 15, Class A, ICES-003:2012, Class A, MSIP (formally KCC/MIC), Class A, TUV Bauart-certified to EN60950-1:2006 +A11+A1+A12, UL recognized to UL 60950-1 2nd edition, VCCI Class A, cUR recognized to CSA22.2, No. 60950-1-07 |
