High Quality Stone Breaker for Granite Crusher Plant

Product Description

High Quality Stone Breaker For Granite Crusher Plant
Application of stone breaker for granite :
This series of stone breaker for granite - jaw crusher manufacturers is mainly used for rough and moderate broken operations of various ore materials those compressive strength are not more than 320 MPa. This crusher has features of high broken ratio, uniform product size, simple structure, reliable operation, convenient maintenance, low operating costs etc, which is widely used in mining, smelting, building, roads, railways, water
conservancy and chemical industry.
Working principle of Stone breaker for granite
Motor drives the eccentric axis rotating through the belt pulley, so that the movable jaw approaches and leaves the fixed jaw cyclical, which makes the materials squeezed, rubbed, multi-roller crusher, etc. So that the materials are crushed into small size, and then decline gradually, at last discharge from the discharging mouth.
stone breaker for granite main technical parameters:

Model	Hopper size (mm)	Max. Feed size (mm)	Capacity (t/h)	Motor Power (kW)	Scope of discharge opening (mm)	Overall dimensions (mm)	Wight (t)
PE-150× 250	150× 250	125	1-5	5.5	10-40	875× 758× 850	0.81
PE-250× 400	250× 400	210	5-20	15	20-60	1450× 1315× 1296	2.8
PE-400× 600	400× 600	340	16-65	30	40-100	1565× 1732× 1586	6.5
PE-600× 900	900× 600	500	50-120	55-75	65-160	2305× 1840× 2298	15.5
PE-500× 750	500× 750	425	45-100	55	50-100	1890× 1916× 1870	10.1
PE-750× 1060	750× 1060	630	52-180	110	80-140	2450× 2472× 2840	28
PE-900× 1200	900× 1200	750	140-260	110	95-165	3335× 3182× 3025	50
PE-250× 750	750× 250	210	15-30	22	25-60	1667× 1545× 1020	4.9
PE-250× 1000	1000× 250	210	16-52	30-37	25-60	1530× 1992× 1380	6.5
PE-250× 1200	250× 1200	210	20-60	37	25-60	1900× 2192× 1430	7.7

stone crusher spare parts:
stone breaker for granite features:
Excellence in casting engineering
-Excellent material intake capacity
-Easy installation & maintenance
-High production and reduction
-Reliability, high availability
Contact:
Sara
Mobile phone : 0086137 8347 1727


Company Website: zzhxpsj.en.made-in-china.com

---
