Product Details
Product Description
Product Description
Application Scenario
Indicated Bus/logistics/industrial fleet charging. Special vehicle charging in airport or mine field
Highlight
High efficiency
System efficiency is higher than 95%, high power density, saving system operation cost.
High power factor, low harmonic distortion, no pollution.
Secure and Safety
With short circuit, over current, over voltage, over charge, anti-reverse connection and other protection functions. Optional smoke sensor, water sensor and other active protection functions.
Tolerance
Excellent cold resistance, high temperature resistance, salt spray resistance, moisture resistance and other functions.
Intelligent Control
Charging status light indicator function, can monitor the machine running status in real time
Convenient maintenance
Core component filled with silica gel.
Failure rate reduction of 90%.
Easy debugging, reduce the difficulty of operation
| Model | TCDZ-DC1.00/120 | TCDZ-DC1.00/160 |
| Power supply | 3P+N+PE |
| Rated voltage | 380VAC±15% |
| Frequency | 50/60Hz |
| Power system | TN-S |
| Output voltage | 50-1000 V DC(300~1000V Constant power) |
| Rated power | 240kW | 320kW |
| Max current | 250A |
| Charge connector | GB/T*2 |
| Cable length | 7m |
| Display screen | 8 inch LCD touch screen |
| Language | English/Chinese |
| LED indicator | Green/Yellow/Blue/Red |
| Start mode | Local start: Plug & charge/Password | Network start: APP/VIN |
| Option | Smoke sensor/Water sensor/Anti-tipping sensor |
| Emergency stop | Yes |
| Auxiliary power supply | 12V/24V |
| Network interface | 4G/Etherne |
| Protocol | OCPP1.6J |
| Protection level | IP55/IK10 (not including the screen) |
| Electrical protection | Input over current protection, Ground protection, Surge
protection, Input over/under voltage protection, Output
over/under voltage protection, Over temperature protection,
Input/output short-circuit protection, etc. |
| THDi | ≤5% |
| Power factor | ≥0.99 |
| Efficiency | ≥95%（peak） |
| Standby power consumption | ≤35W |
| Work humidity | 5%~95% |
| Work altitude | ≤2000m |
| Work temperature | -40~65 ℃(-20~50℃ Full load |
| Noise level | ≤65dB |
| Installation | Floor-mounting |
| Product dimension | W950*D750*H1800 mm |
| Net weight | 350kg(Not including charging modules) |
| External package | Wooden case |
| Package dimension | W1290mm*D940mm*H2010mm |
Contact: Nancy
We chat/ Whatsapp86-15376791501
>>
