| US$1.00-4.00 | 1,000 Square Meters (MOQ) |
| (Products Code): | CA260 HWOP (PTFE,PTFE membrane laminated) | |||
| (Testing Item) | Data | Standard, testing situation | ||
| (Basic Weight):G/M² | 260 ±12G | Testing Area: 50CM*50CM | ||
Laminating processing | Thermal pressing | High connecting strength | ||
| , Hierarchical & washable degree | , Membrane not escape after devastate kneading, washable repeatedly | |||
| (Thickness):MM | 0. 62 ±0. 05MM | GB/ T3923. 1-1997 (Tested Area):1 00 MM² (Pressure): 0. 5KPa | ||
| Tensile Strength: | MD CD | >950 N/5CM >800 N/5CM | GB/ T3923.1-1997 Strip Sampling | |
| : Elongation | MD CD | >40% >35% | GB/ T3923.1-1997 Strip Sampling | |
| : Air Permeability | 70 L/ M².S | GB/ T5453-1997 (Tested Area): 100 CM² (Pressure): 200Pa | ||
| Filter Grade | H11 | EU standard | ||
| :°C Continuous working temperature | 120°C | |||
| : Heat Shrinking | MD CM | 2.0 ±0. 15 % 1.0 ±0. 15 % | (Temperature): 180°C (Heating Time): 10 Min. | |
Appearance Defects | ≤3 (Width < 1. 5M) ≤4 (Width > 1. 5M) | Company Standard | ||
| () Percentage of roll with one joint | ≤10% | Company Standard () (Roll QTY with one joint divided by total roll QTY) | ||
| (Length per roll) | 400 ±10 Meters | Can be customized | ||
