| Specification | Unit | Z3080x25/1 |
| Max. Drilling dia. | mm | 80 |
| Distance from spindle nose to table | mm | 330-1585 |
| Distance from spindle nose to table | mm | 500-2570 |
| Spindle travel | mm | 400 |
| Spindle cone | | MT6# |
| Spindle speed range | r/min | 16-1250 |
| Spindle speed step | | 16 |
| Spindle feeding range | mm/rev | 0.04-3.2 |
| Spindle feeding step | | 16 |
| Rocker rotary angle | deg | ±90 |
| Main motor power | kW | 7.5 |
| Movements motor power | kW | 1.5 |
| Machine dimensions | mm | 3600*1450*3300 |
| Machine weith | kg | 9400 |
| Packing dimensions | mm | 3620*1400*1490(wood case)
3830*1230*2180(wood case) |
| Hercules Machinery Equipment Ltd. |
1. Keyless drill chuck
2. Connecting rod
3. Reduction sleeve
4. Withdrawl wedge
