Plastic20L 30L Water Drum Blow Molding Machine Machinery

Product Description

Company Profile

Product Description
Automatic HDPE Jerry Cans making machine energy saving type
Extrusion blow moulding machine
Jerry cans blow moulding machine
Model No.: ABLD90(single station single die head)
ABLD80 extrusion blow moulding machine was specially designed for making plastic water tanks, plastic cans, lubricant oil bottles, plastic drums, plastic toys and other plastic containers not over 25L.
The features of this machine:
(1)It is suitable for producing PE, HDPE, PP, PVC so on, plastic containers and bottles in all shapes are available, the max. Product volume is up to 30L.
(2)Single station single die head design, very easy to operate and maintenance.
(3)Most components of the blow moulding machine are from famous world brand.
(4)Fully automatic process with low power consumption, high efficiency, quick and safe operation, easy for maintenance.
(5)Accumulation die head, MOOG parison controller equipped.
(6)Bottom blow technology make the product perfect.
(7)Auto lubricant system controlled by PLC.
Main parts of Machine Picture Explanation Product Parameters

Max. Product volume	60 liters
Dry cycle	450pc/h
Screw diameter	90mm
Screw L/D ratio	25 L/D
Screw drive power	37 KW
Screw heating capacity	18 KW
No.of heating zone	4 zones
Output of HDPE	130 KG/H
Oil pump drive power	30 KW
Clamping force	260 KN
Max.size of mold	450-1000mm
Mold stroke	700X950mm
Max.die diameter	340mm
Die heating power	7.6 KW
Die heating segments	4 zones
Blowing pressure	0.8mpa
Air volume	1.0 M³/MIN
Cooling water pressure	0.3mpa
Water consumption	90 L/MIN

This part is the full electric components of the machine:
Contact us

After-sale Service:
1. One year warrantly after sale.
2. Provide technical advisory service for a long time.
3. Professional after-sale service.
4. If there is any problem with the machine , or any main parts are broken, we will ask our profesionals and technical personnel to repair it or replace it for free.
5. We will train two or three operating man for free.
(Travel and hotel is paid by buyer's expenses.)
Sample Service:
1. The video of how machine running will be sent to you.
2. Welcome to China and come to visit our company. We will show you around to see how the machine running. If you have any problem, we must give you a very detailed explanation.
3. All of us will try our best to help you have a full understanding of our machine so that you can opeate your machine easily and put the machine into use as soon as possible.
