Horizontal Lathe Machine CW6283C/4500

US$10,000.00-100,000.00 1 Piece (MOQ)

Basic Info.

Model NO.

CW6283C/4500

Processing Accessory

pipe and flange type metal workpiece

Guide Rail

Horizontal Guide Rail

Tool Holder

4 Stations Tool Post

Power Source

Electric

Controlling Mode

Artificial

Automatic Grade

Manual

Setting Mode

Floor-type

Precision

High Precision

Certification

CE, ISO 9001

Condition

New

Max Swing Over Bed

830mm

Distance Between Centerm

4500mm

Transport Package

Wooden Pallet

Specification

CW6283C/4500

Trademark

HAVEN

Origin

China

HS Code

8455

Production Capacity

100units/Month

Product Description

Horizontal Lathe Machine CW6283C/4500
Main feature:
This series horizontal lathe has good reputation in this line and populated by customers in domestic and abroad. It including: CW663C, CW6 73C,CW683C, CW693C, ect. Distance between centers are 750mm,1000mm,1500mm,2000mm,3000mm,4500mm,6000mm
Main specification:

Model		Unit	CW6163C CW6263C	CW6173C CW6273C	CW6183C CW6283C	CW6193C CW6293C
Swing over bed		mm	630	730	830	930
Swing in gap		mm	800	900	1000	1100
Swing over cross slide		mm	350	450	550	650
Distance between centers		mm	750,1000,1500,2000,3000,4500,6000
Length in gap from face plate		mm	300
Spindle nose			Cll or D11
Spindle bore		mm	105,130
Spindle speeds		rpm/steps	10_800/18
Cross slidle travel		mm	480
Top rest travel		mm	225
Rapid traverse		mm/min	:3200, :1900
Quill diameter		mm	90
Quill travel		mm	260
Quill taper			MT5
Bed width		mm	550
Metric threads		mm/kinds	1_240/53
Inch threads		tpi/kinds	30_2/31
Module threads		mm/kinds	0.25_60/46
Diametral pitch threads		Lpi/kinds	60_0.5/47
Main motor power		kw	11
Packing size	Length	mm	3460,3390,3795,4330,5310,6810,8310
	Width	mm	1400
	Heigth	mm	2000
Gross weight		Kg	4250	4450	4650	4900
			4500	4700	5100	5300
			5000	5200	5600	5800
			5500	5700	6100	6300
			6200	6400	6600	6900
			7300	7500	7600	7900
			8300	8500	8600	8700
