Glass Hanging Bar Glass Lifting Bar Beam Glass Lifting and Transport

Product Description

Glass Lifting Bar

Description
The hanging bar has many advantages. Based on the different sizes of the glass pack, the hanging bar is universal for the glass length from 2000mm-3600mm.
Designed in accordance with the principles of mechanics, the longitudinal and transverse bearing capacity is precisely calculated, and a new style of perfectionist suspension bar is designed by using the 3D model.
The diameter of seamless steel pipe ups to 146mm. The industrial-grade welding machine is used for deep penetration welding, and the welding point is polished finely without damaging the sling to ensure the safety of use. The surface is treated with epoxy paint to prevent rust and corrosion, UV, strong adhesion, and long service life. There are eye-catching specifications on each position of the strap, which is more worry-free. Can be more customer requirements, special customization.
Features
Suitable for different size glass
Seamless steel pipe with diameter ups to 146mm
Smooth surface makes zero damage to the glass sling
Epoxy paint, anti-rust, and anti-corrosion
Eye-catching specification
Specification

Model	RSY-XSDGO8
Capacity	4 tons
Length	3150mm
Diameter	146mm
Suitable glass length	2000,2200,2400,3050,3300,3600(mm)
Slots number	8

Picture Showing:
