Our Advantages 1. Program and functional test and package by Free.
2. High quality: IPC-A-610E standard, E-test, X-ray, AOI test, QC, 100% functional test.
3. Professional service: PCB Layout, PCB/FPC/Aluminium Making, SMT, DIP, Component Sourcing, PCB Assembly, Housing and assembly,
Box Building, OEM Service.
4. Certifications: 94v-0, CE, SGS, FCC, RoHS, ISO9001, ISO14001, ISO13485, TS16949
5. The warranty period for PCBA: 2 years.
6. About Factory: 16 SMT Lines, 4 DIP Lines, 1 X-Ray, 32 AOI, 2 Sample test machines.
| 1 | Material | FR4, (High Tg FR4, General Tg FR4, Middle Tg FR4), Lead-Free Solder Sheet, Halogen Free FR4, Ceramic Filling Material, PI Material, BT Material, PPO, PPE etc. |
| 2 | Board thickness | Mass production: 394mil(10mm) Samples: 17.5mm |
| 3 | Surface finish | HASL, Immersion Gold, Immersion Tin, OSP, ENIG + OSP, Immersion Silver, ENEPIG, Gold Finger |
| 4 | PCB Max panel size | 1150mm × 560mm |
| 5 | Layer | Mass production: 2~58 layers / Pilot run: 64 layers, Flexible PCB: 1-12 Layers |
| 6 | Min hole size | Mechanical drill: 8mil(0.2mm) Laser drill: 3mil(0.075mm) |
| 7 | PCBA QC | X-Ray, AOI Test, Functional Test |
| 8 | Special Process | Buried Hole, Blind Hole, Embedded Resistance, Embedded Capacity, Hybrid, Partial hybrid, Partial high density, Back drilling, and Resistance control. |
| 9 | Our service | PCB, Turnkey PCBA, PCB Clone, Housing, PCB Assembly, Component sourcing, PCB manufacturing from 1 to 64 layers |
| 10 | Sanforized | Buried via, Blind via, Mixed Pressure, Embedded Resistance, Embedded Capacitance, Local Mixed Pressure, Local High Density, Back drill, impedance control. |
| 11 | SMT Capacity | 700 Million Points/Day |
| 12 | DIP Capacity | 5 Million Points/Day |
| 13 | Certificate | CE/RoHS/ISO9001/ISO14001/ISO13485/TS16949 |
