Apollo PTP series large format printer, available with 1.8m/3.2m, KM256/512 head optional, competitive, indoor quality.
Technical Specifications for Apollo PTP series Large Format Printer :
Model
| PTP1804/PTP3204
| PTP1806/PTP3206
| PTP1808/PTP3208
|
Print Tech.
| Piezo continuous drop-on demand(DOD)
|
Print head
| 4×KM256/4×KM512
| 4×KM256/4×KM512
| 4×KM256/4×KM512
|
Print Width
| 1.8m/2.5m/3.2m
|
Printing Speed
| Draft Mode38m2/h
Poduction Mode: 27m2/h
Quality mode: 13m2/h
| Draft Mode57m2/h
Poduction Mode: 41m2/h
Quality mode: 13m2/h
| Draft Mode76m2/h
Poduction Mode: 54m2/h
Quality mode: 26m2/h
|
Resolution
| Max360×1440/720×1080
|
Heating System
| Front and back heater equipped
|
Ink type
| CMYK
| CMYKLcLm
| CMYK
|
Media Type
| Banner, Vinyl, Coating Film, Mesh, etc
|
Media Transmission
| Roll to Roll
|
Interface
| USB2.0
|
Auto. Feeding System
| Equipped
|
Auto. Take-up System
| Optional
|
Fan drying System
| Equipped
|
G. Weight
| 380Kg
|
Packing Size
| 4800mm×810mm×1060mm
|
Power Requirement
| 220V±10,10A,50/60HZ
|
Environment
| Temperature20~25Humidity40%RH~70%RH
|
Outdoor Durability
| 2 years
|
Specifications are subject to change without prior notice.
Highlight Features:
1. Modern design,rigid mechanic system.
2. Konica head, branded linear guider and servo motor enables high quality print.
3. Optical fiber data transmission, Anti-interference, more stable data transfer.
.
4. Separated location of strong and weak current, higher security.
5. New platform adsorption function, greatly enhanced the reliability of Vinyl printing.
6. 4/6/8 heads can be upgrade to each other directly without any changes.
7. Auto. positive pressure and head auto. cleaning system, greatly reduced the time and process of head maintenance.
8. Double head filtration, double insure of head lifetime.
9. Independent LIYU control software with Bi-direction blank-jump and feather printing functions: save your precious time and improve your printing quality.
