Oil Free Dry Claw Vacuum Pump Air Cooling / Water Cooling

Product Description

Claw Vacuum Pump (RC100)
Product Description
With claw vacuum pumps, two claw-shaped rotors turn in opposite direction inside the housing. Due to the shape of these claw rotors, the air or gas is sucked in, compressed and discharged. The claw rotors do not come into contact either with each other nor with the cylinder in which they are rotating. Tight clearances between the claw rotors and the housing optimise the internal seal and guarantee a consistently high pumping speed. A synchronisation gearbox ensures exact synchronisation of the claw rotors.Claw vacuum pumps are driven by a directly flange-mounted asynchronous motor, with an efficiency class IE2. Claw vacuum pumps are ideally suited to use with frequency-controlled drives. Claw vacuum pumps are available in a wide range of sizes.There are also variants for special applications such as dust and gas explosion protection, high steam contents, gas tightness and increased oxygen contents.
Product Parameters

Product Model	50/60Hz	RC100
Pumping Speed	50Hz	100m³/H
	60Hz	120m³/H
Ultimate Pressure	mbar	70
Inlet Diameter		G1 1/4''
Voltage	50Hz	380-415V
	60Hz	380-440V
Motor Power	kW	3
Rotate Speed	r/min	2980
Noise Level	dB	80
Net Weight	kg	185

Detailed Photos
Installation Instructions
Certifications
Company Profile

---
