| Model | GL-200A | GL-300A | GL-400A | GL-500A | GL-600A |
| Width of Material (mm) | 200 | 300 | 400 | 500 | 600 |
| Thickness of Material (mm) | 0.4-2.5mm | ||||
| Coil Weight (Kg) | 800kg | 1000kg | 1500kg | 2000kg | 3000kg |
| Coil I.D.(mm) | 450-530mm | ||||
| Coil O.D.(mm) | 1200mm | ||||
| Straightener Motor(HP) | 1.5HP | 2HP | 2HP | 3HP | 3HP |
| Reduction Box | |||||
| Feeding Speed (m/min) | 15M/Min | ||||
| Power Supply | AC 3 Phase 380V | ||||
| Feeding Roller | ∅63 UP 2/Down 2 ∅79.5 | ||||
| Straightener Roller | ∅57 Up 3/Down 4 | ||||
| Uncoil Expansion | Hydraulic Expansion | ||||
| Machine Features 1.The material rack and the straightening machine are integrated to reduce the installation space, reduce the transition link in the process of straightening precision materials, and maximize the performance of the machine. 2.The material rack and the straightening machine are controlled separately by independent electric boxes, and each uses a frequency converter to make the movement smooth and more effectively protect the machine, so that it will not be deformed and twisted by various external forces during the movement. 3.The straightening machines are all universal joint transmission and full gear transmission, which effectively avoids the damage to the material caused by the rotation of the roller. 4.The straightening wheel contains a dial indicator, which can quickly find the leveling point. . 5.The addition of the straightening back pressure wheel strengthens the rigidity of the straightening wheel and makes the straightening effect more superior. 6.The addition of the lubrication system increases the service life of the machine. It can be modified and customized according to the customer's needs for the sealing rack load and the correction parameters, and can be equipped with a powered or unpowered material rack, a press pipe arm, and a hydraulic expansion according to the needs. | |||||
| ●Product features: 1. The material rack and the precision thin plate leveling machine are optimally combined together, which is suitable for the leveling of stainless steel plates, copper plates, aluminum plates and other products with high surface and precision requirements between 0.3 and 1.5 mm. 2. The upper roller seat can be lifted at 45 degrees, which is convenient for cleaning and maintenance of the roller, and completely avoids scratches on thin plate materials. 3. The leveling roller adopts vertical transmission, upper 3/lower 4 structure, and the upper leveling assembly is equipped with an auxiliary roller. The bending direction of the material can be adjusted according to the needs. The full-drive correction design can improve the surface flatness of the plate, which is suitable for the needs of high-precision and high-requirement processing. 1. The roller adjustment adopts the pioneering scoring adjustment method instead of the traditional dial indicator adjustment method. No additional correction is required, and the debugging is simpler, more accurate, and the service life is longer. 2. The leveling wheel is made of bearing steel (SUJ2), which is heat-treated HRC60°, hard chrome-plated on the surface, and then ground to have high hardness, high wear resistance and long service life. 3. This machine adopts dual frequency converter control, which can reduce the scratches on the material surface caused by startup and reduce the damage rate. 4. It can also be used for shearing production lines of long-sized materials. | |||||
| ●Standard accessories: Floor-type induction device Four-point fine-tuning device (with dial indicator) Drag rack A-shaped material stop rack X4 pieces ●Special accessories: Leveling machine inverter Material rack power system Material rack inverter Material rack hydraulic expansion device Cylinder pressing arm Fixed material stop rack Photoelectric induction device Feeding trolley: can rise and fall, move forward and backward, and feed automatically ●Typical applications: Automatic stamping and leveling operations for electrical hardware, automotive hardware, mechanical hardware, air conditioning hardware, and kitchen and bathroom hardware. | |||||
