Product DescriptionHY1004 Laboratory Drawing Frame is part of the mini spinning system. It’s mainly used in university, researching center etc. and it is used to attenuate and straighten fibers by having them pass, in sliver form, through a series of double rollers, each pair of which revolves at a slightly greater speed than the preceding pair and reduce the number of strands originally fed into the machine to one extended fibrous strand doubled or redoubled in length.Features1. Laboratory Drawing Frame adopted imported frequency converter control, high efficiency.2. Mini type machine, save researching cost and easy to operate and maintain3. Can perform four functions in one machine, open cotton bale, remove impurities, blend cotton and lapping.4. Can be used for cotton fiber or wool fiber (alternative)with different machine partsSpecification ModelHY1004 Laboratory Drawing FrameFiber typeCotton or wool (alternative)Draw structure3 up and 3 downDraw ratioApprox. 2~10Fiber length22 ~ 64 mm or customizedOutput capacity0.25 ~ 1 kg per hour or customizedRoller diameterΦ35mmOutput speedApprox. 12m/minCan sizeΦ250*550mmPower220V/380V, 50/60Hz, 950WDimension1200*800*1200mm
>>
