Doube Clolumn Heavy Duty Ck5225 Ck5240 Ck5250 Ck5263 CNC Vertical Lathe Machine

Product Description

Doube Clolumn Heavy Duty CK5225 CK5240 CK5250 CK5263 CNC Vertical Lathe Machine
Product Description
Technical specifications:

Specification	Unit	CK5225D	CK5240D	CK5250D	CK5263D
Table diameter	mm	2250	3200	4500	5700
Max. turning diameter	mm	2500	4000	5000	6300
Max. height of workpiece	mm	1600	1600	2000	3150
Max. weight of workpiece	T	10	16	32	50
Table speed steps		4 steps stepless	4 steps stepless	4 steps stepless	4 steps stepless
Table speed range	rpm	2~63	2~63	0.5~40	0.5-40
Max.torque of table	KN·m	63	63	70	100
Max.cutting force of right vertical tool post	KN	35	35	35	40
Horizontal travel of right vertical tool post	mm	-50~1400	-50~2150	-50~2770	-50~3450
Vertical travel of right ram	mm	1000	1000	1250	1600
Right vertical tool post feed range	mm/min	0.1--500	0.1--500	0.1--500	0.1--500
Max.cutting force of left vertical tool post	KN	30	30	30	30
Horizontal travel of left vertical tool post	mm/min	-50~1400	-50~2150	-50~2770	-50~3450
Vertical travel of left ram	mm	1000	1000	1250	1600
Left vertical tool post feed range	mm/min	0.2--145	0.2--145	0.2--145	0.2--145
Swivel angle of vertical tool post	°	-30~+30	-30~+30	-30~+30	-30~+30
Left ram section size	mm	255×200	255×200	255×200	255×200
Tool section size	mm	40×50	40×50	40×50	40×50
Vertical tool post rapid traverse	mm/min	R:2000 L:1550	R:2000 L:1550	R:2000 L:1550	R:2000 L:1550
of cross beam	mm	1250	1250	1650	2650
Cross beam lifting speed	mm/min	350	350	350	350
Cross beam lifting motor power	kw	11	11	11	11
Main motor power	kw	55	55	70	70
Overall dimensiont	mm	5180*4700*5300	5180*4700*5300	5180*4700*5300	5180*4700*5300
Machine weigh	T	35	43	65	90

Company Profile


Certifications

FAQ
1: Where is your company
A: Our company is located in Tengzhou City, Shandong Province.
2: What about your warranty?
A: Warranty is one year. During warranty time, if the parts are damaged because of Nonhuman factors, we will send new replaced parts for free
3: How do you offer after-sale service?
A: We usually offer technical support online by wechat or whatsapp. Customer describe the problems and send videos and pictures, our technician will help to solve the problems
4. What is your standard package?
A: Our package is export standard plywood case with pallet.
5: What's the Payment Terms?
A: T/T, 30% initial payment when order, 70% balance payment before shipment;
6: What's the MOQ?
A: 1 set.

---
