Horizontal Type Class C /R160- Volumetric Rotary Piston Water Meter

Product Description

Volumetric water meter
Specifications
Class C, R160, brass body, Plastic lid, 3/4"
Features:
Rotary piston system. Long service life
Dry-dial or liquid sealed register, keeps clear reading for long time° C
High measuring accuracy, the starting flow of the meter is 2 L/Pulse or less
Can be installed in any position
Brass body, m³ Or gal, optional
Remote transmisson can be added upon request
Many kinds of sensors, such as Reed Switch, Hall and Weagand can be supplied upon request
Pulse output maybe 1L/Pulse
ISO 4064: 1993 Class C
ISO 4064: 2005 R160/R200;
Working condition:
Water temperature 50° C
Water pressure≤ 1MPa
(PN: 1.6MPa/16bar)
Δ P≤ 0.1MPa(Class C/Class D)
Δ P≤ 0.063MPa(R160/R200)
Accuracy:
From minimum flow-rate(qmin/q1)inclusive, to transitional flow-rate(qt/q2), exclusive: ± 5%
From transitional flow-rate (qt/q2)inclusive, to overload flow-rate(qs/q4), exclusive: : ± 2%

DN/Q	Q4=1.25Q3 Q3	R=Q3/Q1	Q2=1.6Q1 Q1	R=Q3/Q1	Q2=1.6Q1 Q1
	l/h		l/h		l/h
20	5000 4000	160	40 25	200	32 20

Nominal size DN9mm)	Classof measurement	Overload flow-rate q s	Permanent flow-rate q t	Transitional flow-rate q t	Minimum flow-rate q min	Minimum reading Min	Maximum reading Max
20	C	5	2.5	37.5	25	0.0001	9999

Overall dimensions and weight:

Type	Size(mm)	Length(mm)L	Width(mm)W	Height(mm)H	Connecting Thread D	Weight (kg)
LXH-15	15	270	165	90	G1"B	1.8

---
