Klt-P6ma-Imx258 V1.2 13MP Imx258 Mipi-Schnittstelle Autofokus Kameramodul

Product Description

13MP IMX258 MIPI-Schnittstelle Autofokus Kameramodul
Kameramodul Nr. KLT-P6MA-IMX258 V1.2

Kameramodul Nr.	KLT-P6MA-IMX258 V1.2
Auflösung	13MP
Bildsensor	IMX258
Sensorart	1/3.06"
Pixel Größe	1.12 um x 1.12 um
EFL	2.80 mm
F.NO	1.90
Pixel	4224 x 3136
Betrachtungswinkel	90.3°(DFOV) 77.4°(HFOV) 62.0°(VFOV)
Linsenabmessungen	8.50 x 8.50 x 5.35 mm
Modulgröße	26.43 x 8.50 mm
Modultyp	Autofokus
Schnittstelle	MIPI
Autofokus-VCM-Treiber-IC	DW9763
Linsenmodell	KLT-LENS-50013A1
Linsentyp	650 nm IR-Schnitt
Betriebstemperatur	-20°C to +70°C
Gegenstecker	BBR43-30KB533
