| Negotiable | 1 SET (MOQ) |
| Specification Table | LTY-5800 | ||||
| A | B | C | |||
| Injection Unit | Screw Diameter (mm) | 90 | 95 | 100 | |
| Screw L/D Ratio (L/D) | 18.5 | 17.5 | 16.6 | ||
| Shot Size(Theoretical) (cm³) | 2544 | 2815 | 3140 | ||
| Injection Weight ( g) | 2315 | 2580 | 2858 | ||
| Injection Rate (g/s) | 470 | 530 | 580 | ||
| Plasticizing Capacity (g/s) | 75 | 88 | 110 | ||
| Injection Pressure (Mpa) | 184 | 165 | 149 | ||
| Screw Speed (rpm) | 125 | ||||
| Clamping Unit | Clamping Force (KN) | 5800 | |||
| Toggle Stroke ( mm) | 850 | ||||
| Space Between Tie-Bars (mm) | 840X820 | ||||
| Max.Mould Height (mm) | 850 | ||||
| Min. Mould Height (mm) | 350 | ||||
| Ejector Stroke (mm) | 225 | ||||
| Ejector Tonnage (KN) | 150 | ||||
| Other | Max.Pump Pressure (Mpa) | 16 | |||
| Pump Motor Power (KW) | 55 | ||||
| Heating Power (KW) | 25 | ||||
| Machine Dimensions(LxWxH) (m) | 9X2.3X3.7 | ||||
| Machine Weight(Approximate ) (t ) | 26 | ||||
