Moving Surface Grinder Fsg-2050m Saddle

Product Description

table size	mm	200*508
magnetic chunck size	mm	200*460
max.distance from spindle center to table	mm	450
table cross travel	mm	240
table longgitudinal travel	mm	560
max .loading capacity(include chuck)	kg	180
speed of table longitudinal move	m/min	5-25
cross motion
intermittent feed rate	mm/t	0.1-8
rapid speed	mm/min	990
feed of handwheel	mm/div	0.02
vertical motion
auto down feed rate	mm/t	0.005-0.5
rapid down speed	mm/min	480
feed of handwheel	mm/div	0.005
spindle rotating speed	r/min	2850(50HZ)/3450(60HZ)
grind wheel; size	mm	200*20*31.75
spindle motor power	kw	2.2
floor space	mm	2300*1600*1675
package size	mm	2000*2100*2150

The grinding machine is a versatile and efficient tool used for various applications in the manufacturing industry. It is designed to remove excess material or shape workpieces with precision and accuracy. The machine utilizes an abrasive wheel or belt to achieve the desired result. One of the key advantages of the grinding machine is its ability to produce a smooth and polished finish on different materials, including metals, plastics, and ceramics. This makes it ideal for tasks such as surface finishing, deburring, and sharpening tools. The machine's operation involves rotating the abrasive wheel or belt at high speeds, which creates friction against the workpiece. As a result, the excess material is gradually removed, and the desired shape or finish is achieved. The grinding machine can be operated manually or automatically, depending on the complexity of the task. In addition to its versatility, the grinding machine offers excellent precision and accuracy. It is capable of achieving tight tolerances and fine surface finishes, making it an essential tool for industries such as aerospace, automotive, and medical. Furthermore, the grinding machine is designed for durability and reliability. It is built with high-quality components and features a robust construction to withstand the demands of heavy-duty applications. Overall, the grinding machine is an indispensable tool in the manufacturing industry. Its ability to remove excess material, shape workpieces, and produce smooth finishes makes it a valuable asset for any production facility.

---
