Jy260vf Small Lathe Machine, Bench Lathe with High Rigidity High Quality

US$600.00-800.00 1 Piece (MOQ)

Basic Info.

Model NO.
JY260VF
Power Source
Manual
Automatic Grade
Manual
Setting Mode
Table
Precision
High Precision
Certification
GS, CE, RoHS, ISO 9001
Condition
New
Max. Turning Dia
280mm
Two Top Distance
700mm
Max. Turning Dia of Middle Carrage
172mm
Top Slide Travel
63mm
Cross Slide Travel
140mm
Spindle Bore
38mm
Spindle Taper
Mt5
Travel of Tailstock Sleeve
94mm
Spindle Speed Range
50~1800rpm
Metric Threads Range
0.2-3.5mm
Inch Thread Range
8-56t.P.I
Motor Power
1.1kw
Taper of Tailstock Quill
Mt3
Machine Size
1260X620X525mm
G.W./N.W
208/245kg
Transport Package
Wood CTN
Specification
1260x620x525mm
Trademark
JYME
Origin
China

Product Description


Chizhou Jingyi Electromechanical is a professional machinery manufacturing service provider. The factory has a full range of shears, saws, lathes and other processing equipment. The product styles are complete. The products are made of high-quality materials and advanced processing technology. The quality is guaranteed. All products can provide good training and technical services. Welcome new and old customers to inquire.
