Angle Profile Processing Machine Fincm Cnc Angle Hole Punching Machine Fabrication

Product Description

Product Description
APM1412S FINCM Hydraulic Angle Steel Tower Angle Line CNC Punching Shearing Marking Machine
It is mainly used for customers to manufacture angle steel components, complete typing, punching, fixed length cutting on angle steel. Simple operation, high production efficiency.

Technical specification of APM1412S:

Model	APM1412S
Angle Size	40x40x3~140x140x8mm(Q345)
Max. workpiece length	12m
Max. punching capacity(DxT)	Φ25.5mm x8mm
Nominal punching force	350KN
Nominal marking force	1030KN
Nominal cutting force	1800KN
No. of character group	4 Piece
No. of character in each character group	18 Piece
Character size	14x10x19mm
Range of stadia	20~170mm (stepless)
No. of punch on each side	3piece
Max. feeding speed	40m/min
No. of CNC axes	3piece
Overall size	25x7x2.2m
Total power	31.4Kw
Machine weight (kg)	Approx. 15000kg

Angle feeding Speed: 40m/min, the effiency is about 1000 holes/hour
The finished angle conveyor is rotated to one side by pneumatic power. The max. Length of finished angle is 8 m.
There are four transverse conveyors which can infeed automatically.
Type of programming: Keyboard input, USB interface input, floppy disc input.
Working environment:
Working temperature: 0~ 40 degree
Power: Three phase four wire system
AC Voltage: 380V
Fluctuation of voltage: ± 10%
Frequency: 50 Hz
Main outsourcing components list of APM1412S:

No	Name	Brand	Manufacture
1	AC servo motor	Delta	Taiwan China
2	PLC	Delta	Taiwan China
3	Electromagnetic valve	Atos/Yuken	Italy/Tawan
4	Relief valve	Atos/Yuken	Italy/Tawan
5	Double vane pump	Albert	USA
6	Air valve	SMC/Airtac	Japan/Taiwan China
7	Cylinder	SMC	Japan

Relateed Products
Company Profile
Shandong FIN C N C MACHINE CO., LTD is located in Jinan high tech Development Zone, is committed to the development, research, design, manufacture, sales of CNC machine tools, such as processing angle bar, beam channel profiles, steel plates, tubesheet and flanges. It is mainly used in iron tower, steel structure, heat exchanger, boiler, bridge, truck and other industries.FIN CNC machines exported to 50+ countries across globe market. Our company has strong R & D center with 30 engineers team, they have 20 years of experience ; 280 staff, plant area about 270,000 sqm. Main products: CNC Angle Line, CNC Beam Drilling Sawing Machine, CNC Plate Drilling Machine, CNC Rail Processing Machine, CNC Tubesheet Flange Drilling Machine, Truck beam plate punching machine. The company drafted many China national standards for C N C angle line
Cooperatine Supplier

Product Process Control
Sales Network
Our Service
FAQ
1. When can you arrange shipment?
For machines available in stock, the shipment can be arranged within 15 days after getting advance payment or L/C;
For machines non available in stock, the shipment can be arranged with 60 days after getting advance payment or L/C.
2. What can you do if my machines have problems?
1) We can send you free components if machines are in warranty period;
2) 24 hours service on line;
3) We can assign our engineers to serve you if you want.
3. Do you provide machine operation training?
Yes. We can send professional engineers to the working site for machine's installation, commissioning and operation training.
4. Which machine model shall I choose when I purchase from you?
Please share us your material size and your processing request, then we will recommend our machine most suitable and most cost effective for your work demand.
5. What's your machine's market share in China?
Our market share in China is about 70%+, and we've exported to 50+ countries across the globe market, since year 1998.

---
