Semi-Automatic Cone Shape Cup Silk Screen Printing Machine

Product Description

Product Description
S350 semi-automatic bottle and container screen printer is a well designed and versatile machine. The S350 can screen print on flat and cylindrical objects such as blow molded bottles, cosmetic tubes, aluminum water bottles, drum sticks, glass pipettes, etc. The S350 features quick & simple tooling changeovers, precise mechanical registration & conveniently all controls are on the front panel, making the S350 the perfect all around universal screen printing press.
Standard Features:
1.Pneumatic controlled with shock absorbers
2. Microprocessor controlled - PCB
3.Vertical part lift with height adjustment
4.Print stroke controlled with rodless cylinder
5.X/Y/R positioning ware-mounting table
6.Linear ball bearings on hardened shafts
7.Squeegee tilt, skew, and height adjustable
8.Screen frame angle & tilt adjustable
9.Synchronized bottle inflation system with regulator
10.Regulated squeegee pressure with pressure gauge
11. Floor levelers & casters
12.Foot switch controlled
Tech-data

Model Number:	APM-S350
Drive System:	Pneumatic
Frame Up/Down Stroke:	100mm (3.94")
Maximum Print Area Round: Maximum Print Area Oval: Maximum Print Area Flat:	110mm (4.33") Ø 340mm (13.39") Arc Length 200 x 320mm (7.87" x 12.60")
Working Table Size:	250 x 350mm (9.84" x 13.78")
Table Adjustment:	X,Y ± 15mm / θ 15 °
Maximum Screen Frame Size:	380 x 580mm (14.96" x 22.83")
Screen Frame Thickness:	18 - 25mm (.71" - .98")
Squeegee Angle:	0-15°
Printing Cycle Speed:	1,200 cycles/hr
Squeegee Speed:	20/min
Squeegee Pressure:	2 - 4 Bar
Electric Source:	110V/220V 50-60Hz 50W
Air Pressure Input:	80 psi
Air Consumption:	0.7 L/cycle
Machine Weight:	150 kg (330.69 lbs)
Machine Weight (including crating):	230 kg (507.06 lbs)
Dimensions (L x W x H):	1,000 x 950 x 1,400mm (39.37" x 37.4" x 55.12")
Crate Dimensions:	1,080 x 1,010 x 1,520mm (42.52" x 39.76" x 59.84")

Applications
Cylindrical/oval/square plastic/glass bottles with UV ink or solvent ink printing.
Printing objects such as bottles, cups, cans, bath bottles, shampoo bottles, cosmetic bottles, etcPackaging & Shipping
Customer reviews
Company Profile
Company ProfileAutomatic Packaging Machinery Co., Ltd. (APM) We are the top supplier of high quality automatic screen printers, bronzing machines, pad printing machines, advertising automatic lines, UV spray lines and accessories. All machines are manufactured according to CE standards.
With more than 20 years of R&D and manufacturing experience, we are fully capable of supplying various packaging machines, such as wine bottles, glass bottles, water bottles, cups, mascara bottles, lipsticks, bottles and jars, power boxes, shampoo bottles, barrels, etc.
Exhibition pictures
FAQ
FAQ
Q:How to order from your company?
A:Please send us inquiry and online inquiry through Made in China or our official website. Then our sales will reply the quotation to you. If the customer agrees to the offer, the company will sign a sales contract. Next, the buyer fulfills the payment obligation and the dstar machine starts production to the order.
Q:Can we print samples to check the quality?
A:yes
Q:Is there operation training?
Yes, we offer free training on how to install and use the machine, and more importantly, our engineers can go overseas to repair the machine!
Q:How long warraty of the machine?
A:year+lifelong technical supports
Q:Which payment item do you accept?
A: L/C (100% irrevocable sight) or T/T (40% deposit + 60% balance before delivery)

---
