| LP141- SPEC |
| Type | Item | Description | Remark |
| product type | Notebook | |
| LCD | Size | 14" | |
| Ratio | 1920*1200 16:10 | |
| Touch Panel | NA | |
| Physical parameter | Front | plastic cement | |
| Tilt adjust | 180° | |
| Kingston Lock | Support | |
| Weight | 1.4kg | |
| Packing Size | 314.40*220.00*19.9mm | |
| I/O Port | Left | |
| DC JACK | 3.5-head standard DC interface | |
| USB Type_C | 1*Type-C data only | Optional Full functionality |
| HDMI | 1*HDMI 1.4 | |
| USB Type_A | 1*USB3.2 Gen1 | |
| right | |
| headset | 1*Ø3.5mm Combo | |
| USB Type_A | 2*USB3.2 Gen1 | |
| card reader | TF card reader | |
| RJ45 | Optional | |
| indicator light | Charging light | Left side of C shell | |
| power light | Top left front of C shell | |
| keyboard | Backlight | YES | |
| layout | US | Optional |
| Hardware |
| CPU | type | intel Alder Lake I5-1235U/I7-1255U/I3-1315U | Supports 12-13 generation U/P series CPUs |
| parameter | 12th generation 10-core, main frequency 1.7G, maximum frequency 4.5G, cache 12M, power consumption 15W | |
| GPU | type | Intel® Iris® Xe Graphics eligible | |
| Memory | RAM | 16GB,2*LPDDR4 | |
| Storage | ROM (eMMC/UFS) | NA | |
| SSD | Optional | support64GB/128GB/512GB/1TB/2TB |
| Battery | type | Li-polymer Battery | |
| Number of battery cells | 3 battery cells,1 strings | |
| Voltage&Current | 11.5V/5000mAh | |
| capacity | 58Wh | |
| Fast charging | Support | |
| sensor | G sensor | NA | |
| H sensor | Support | |
| key | power key | Integrated into keyboard | |
| camera | front camera | 2MP,HD 1920*1080 | |
| Privacy switch | Support | |
| Touchpad | type | Integrated touchpad | |
| Multi finger touch control | Support | |
| fingerprint | type | Optional | |
| AUDIO | speaker | 8Ω 1W *2 | |
| Audio processor | ALC269 | |
| MIC | DMIC Integrated into the camera | |
| security | TPM | FTPM | Optional DTPM |
| Confidential chip | NA | |
| RTC | RTC | Support | |
| other | | |
| Connectivity |
| WiFi | type | WiFi module wifi5 | Optional wifi 6 |
| agreement | WiFi 802.11b/g/n/ac | WiFi 802.11ax |
| frequency | 2.4G/5G | |
| Bluetooth | type | Integrated module | |
| edition | BT4.2 | |
| Mobile LAN | 4G LTE | NA | |
| Wired network | Gigabit Lan | Support, requires USB adapter | |
| Software |
| OS | Support types | win10/win11 | |
| language | Optional | |
| BIOS/EC | UI specifications | General specifications | |
| Adapter |
| Adapter | input | AC 100~240V | |
| output | 19V 3.42A 65W | |
| Reliability&Certification |
| Reliability | Warranty period | 1 year | |
| ESD | Contact:±4KV,air:±8KV | |
| Certification | EMI | class B | |
| 3C | Support Certification based on customer needs |
| FAQ |
| Q1/Can I take a sample for quality check ? |
| Sure,we offer sample for testing quality . And If you want OEM support , we also could offer different specification for selection , you can contact us on line sales team for support.We can make the samples according to your requirements. |
| |
| Q2/ what's your shipping way? |
| We have shipping partners worked with over years, they can offer various service including DHL /UPS/ FEDEX/ ARMEX etc, as well as airway shipping , railway shipping or sea shipment . try to give the best shipping method to your side . And if you would like to select your own shipping agency it also could be Ok to support |
| |
| Q3/ Can you do OEM service ? |
| Yes, OEM and ODM is our main business ,we do a lot of project or tender order in some countries ,You can contact our one line sales team to get personalized service support. |
| |
| Q4/Can you add logo on the products? |
| A4:Yes,we can. Laser print,Silk print for your choose. |
| |
| Q5.Can you customize package box for us? |
| A5:Sure,our factory produces OEM/ODM. |
| |
| Q6/ How can I do if have problem with products ? |
| All products will be checked at least three times before sending in order to make sure everything is qualified . we offer one year warranty for our products . Send us the pictures or video first time,we will send free replacement spare parts for you. |
