| Negotiable | 1 Piece (MOQ) |
| M1S2+2/FF | |||
| Basic Specification | |||
| DIMENSION | 3200*1200*2000 MM | PAY LOAD | 400 KG |
| F/R TRACK | 860/970 MM | CLIMBING CAPACITY | 30% |
| WHEELBASE | 1670 MM | CHASSIS | ALUMINUM CHASSIS |
| GROUND CLEARANCE | 150 MM | BODY COVER | PP ENGINEERING PLASTIC |
| MIN.TURNING RADIUS | 2.9 M | MAX.FORWARD SPEED | 35 KM/H |
| NET WEIGHT | 400 KG | RANGE | 80-100KM |
| Product Configuration | |||
| MOTOR | ADC 48V 3.7KM MOTOR | TRANSALE | ITALY GRAZIANO AXLE |
| CONTROLLER | CURTIS CONTROLLER 48V 275A | BRAKE SYSTEM | REAR SELF-ADJUSTING DRUM BRAKE |
| BATTERIES | TROJAN T-875 6*8V | STEERING SYSTEM | DUAL SELF-ADJUSTING BRAKE & PINION |
| CHARGER | 48V 20A INTELLIGENT ONBOARD CHARGER | F/R SUSPENSION | MCPHERSON INDEPENDENT SPRING SUSPENSION |
| TYRE | 22*11-10 TYRE | ||
| Item | Description | |
| system | DC system | AC system |
| Passenger Capacity | 4 | 4 |
| Climbing capacity(full load) | 30% | 35% |
| Max. forward speed | 23km/h | 45km/h |
| Endurance mileage | 70-90km | 80-90km |
| Charging time | 8-10 hours | 8-10 hours |
| Max. loading weight | 360kgs | 360kgs |
| Min. turning radius | 2.9m | 2.9m |
| Max. movement after brake at speed of 20km/h | ≤4m | ≤4m |
