plastic extrusion gearbox tandem roller bearings F-81657.T8AR
plastic extrusion gearbox tandem roller bearings F-81657.T8AR With high efficiency, high performance, low noise, long life, customizable characteristics
Tandem bearing radial guide：
The output shaft consists of centripetal bearings (such as needle roller bearings or SL series single row full cylindrical roller shaftsCarry out radial guidance.
Tandem bearing lubrication：
To ensure adequate heat dissipation and lubrication, the T.AR series series thrust bearings are lubricated with circulating oil. Lubrication systems are usually equipped with a lubricating oil filter and cooling unit.
Tandem bearing mounting fit：
When installing T.AR series series thrust bearings, it is recommended to adopt f6 fit tolerance for shaft and F7 fit tolerance for bearing seat hole. In order to achieve uniform load distribution, bearings shall not be tilted after installation. Strict geometric tolerances of adjacent structures must also be observed.
Tandem bearing customization： Series bearings are available in two, three, four, five, six, seven or eight rows depending on the screw center distance, spacing and load size of the sample center. We also accept series bearings of sizes and structures other than samples. If you need non-standard size, our company can also support customization.
Bearing factory Number F-81657.T8AR Bearing
Item code F81657.T8AR f-81657.t8ar
Inner diameter d Standard size,offer drawing to confirm
Outer diameter
D Total height
B weight(kg)
Standard Cage type Steel or Brass Standard
Cage Precision grade Standard precision grade
Bearing Material GCr15 bearing steel
Description Tandem cylindrical roller thrust bearing
UPC/HS code 8482500090
T8AR The Axial Forces Are Supported By A 8 -Stage Tandem Bearing T8AR Combined With An Axial Cylindrical Roller Bearing
>>
