| Product parameters | |
| Performance | |
| Octa core | |
| CPU | Octa-core 64-bit 2.0GHz high-performance processor |
| RAM+ROM | 4GB+64GB(Optional 6GB+128GB) |
| System | Android 13.0 |
| Data communication | |
| WLAN | Dual frequency 2.4GHz/5GHz, support IEEE 802 a/b/g/n/ac protocol |
| WWAN | 2G: GSM (Mobile/Unicom), CDMA (Telecom) |
| 3G: WCDMA (Unicom), CDMA2000 (Telecom), TD-SCDMA (Mobile) | |
| 4G: TD-LTE (mobile), FDD-LTE (unicom, telecommunications) | |
| 5G: Mobile 5G, China Unicom 5G, Telecom 5G | |
| Bluetooth | Support BT 5.0+BLE Transmission distance 5-10 meters |
| GNSS | Support Gps, Galileo, Glonass, Beidou |
| Physical parameter | |
| Dimensions | 211.5 mm x 136.0 mm x 16.3 mm(The thinnest ) |
| Weight | <700g (Depends on device function configuration) |
| Display | 8 " IPS LTPS 1920 x 1200 / IPS LTPS 1280 x 800(Optional) |
| TP | Supports multi-touch Supported gloves and wet hands |
| Battery capacity | Rechargeable polymer battery (3.8V 9000 mAh) |
| Standby time >350 hours | |
| Working time > 12 hours | |
| Support fast charge, removable battery | |
| Charging time < 3 hours | |
| Expansion Card slot | SIM x 1,SIM/TF x1,PSAM x2(Optional) |
| Communication interface | Type-C USB x 1, OTG,USBA x2 |
| Audio | Speaker (mono), Microphone x 2 , Receiver |
| Keypad | Power key x1,Volume Side key x1,User set key x2 |
| Sensors | Gravity sensor, Light sensor, Proximity sensor, Gyroscope, electronic compass |
| Data collection | |
| Barcode scanning | |
| 2D Imager scanner | Honeywell N6703 N5703 |
| 1D Symbologies | UPC/EAN, Code128, Code39, Code93, Code11, Interleaved 2 of 5, Discrete 2 of 5, Chinese 2 of 5, Codabar, MSI, RSS,etc. |
| 2D Symbologies | PDF417,Micro PDF417,GS1 Composite,Aztec Code,Data Matrix,QR Code,Micro QR Code, Maxicode,Hanxin Code,etc. |
| Camera | |
| Rear camera | 13MP color camera/20MP color camera(Optional) Support auto focus,Flash, Anti-shake, Macro shooting |
| Front camera | 5MP color camera |
| Fingerprint | |
| Features | Support fingerprint unlocking and taking pictures |
| NFC | |
| Frequency | 13.56MHz |
| Protocol | Support ISO14443A/B, 15693 agreement |
| Distance | 2cm-5cm |
| Language/input method | |
| Input | English, Pinyin, Five strokes, Handwriting input, Support soft keypad |
| Language | Chinese, English, Korean, Japanese, Malaysian,etc. |
| User environment | |
| Operating temperature | -20ºC - 55ºC |
| Storage temperature | -40ºC - 70ºC |
| Environment humidity | 5%RH--95%RH(no condensation) |
| Drop specification | temperature range, 6 sides can withstand a height of 1.2 meters 30 impacts of falling to the marble floor |
| Sealing | IP66 |
| Accessories | |
| Standard | Adapter, Data cable, Protective film, Instruction manual |
