Full or Low Lift Spring Loaded Bronz Pressure Safety Relief Valve

US$65.00 1 Piece (MOQ)

Basic Info.

Model NO.

A48Y

Certification

CCC, ISO

Temperature

Ordinary Temperature

Closed

Open

Structure

Spring

Material

Stainless Steel

Characteristic

Safety Valve

Design & Manufacture

API 520, ISO 4126

Pre-Temp. Rating

ASME B16.34

Face to Face

API 526, En558 or DIN 3202

Ends Connection

NPT, RF, Rtj

Inspect & Test

API 527, DIN 3230 or ISO 5208

Certificate 1

Dnv CE 0575

Certificate 2

ISO 9001: 2008

Transport Package

Sea Worthy

Specification

API, ISO, BS, JIS, DIN, EN

Trademark

VATAC or OEM

Origin

China

HS Code

84818010

Production Capacity

8000ton per year

Product Description

Full or Low Lift Spring Loaded Safety Relief Valve with Open or Close Bonnet Conform to API 520, ISO 4126
They are tested according to API 527, and marked as per MSS SP-25
1. Construction is as follows

- Full Lift or Low Lift
- For Steam
- Adjusting Set Pressure
- Closed Bonnet or Open Bonnet
- With or Without Lever
- Screwed Ends to ASME B1.20.1
- Flanged Ends to ASME B16.5

2. Main Part & Materials

Part Names	Part Materials
Body	WCB	LCB	WC6	CF8	CF8M	CF3	CF3M
Bonnet	WCB	LCB	WC6	CF8	CF8M	CF3	CF3M
Trim	13%Cr/SS304			SS304	SS316	SS304L	SS316L
Bolts/Nuts	B7/2H	L7/4	B16/4	B8/8	B8M/8M	B8/8	B8M/8M
Suitable Medium	Steam
Suitable Temperature	-29~425 °C	-46~340 °C	-46~340 °C	-196~427 °C	-196~427 °C	-196~427 °C	-196~427 °C

3. Normal Pressure Rating
PN10~PN420, CLASS150~2500
4. Normal Size Range
DN15~DN600, 1/2"~24"
5. Pictures
Final Inspection
Shipment
