Laboratory Chemical Single Wall Glass Reactor Manufacturer

Product Description

Laboratory chemical single wall glass reactor manufacturer
Description:
Single layer glass reactor is an equipment which is a collaboration of vacuum state, distillation, reflux, stirring, oil/water heating, heating mantle.
It can do all kinds of biochemical reactions and synthesis reactions at a constant temperature condition. It is also a colsed system on the whole.
Single glass reactor inner placed reaction solvent which can be stirred, single layer glass reaction kettle is heated by computer control oil bath or electric heating. At the same time, it can be worked at atmospheric pressure or vacuum state, to control the reaction solution reflux and distillation, it is the ideal equipment for modern synthesis chemical, biological pharmaceuticals and making new materials, used for preparation experiment and production equipment.
Feature:
1. Frequency control, AC induction motor, speed digital display constant, brushless, no spark, safe and stable, it can work continuously;
2. Supporting glass using GG3.3 high boron silicon material production, has a good chemical, physical properties; big bottle design, hand out cleaning;
3. PTFE (Ceramic) mechanical component sealing, proprietary technology, it can get the best vacuum degree in the market among the similar products;
4. Overall stainless steel frame structure (foot connecting parts like Tee and four-way valve are all stainless steel), compact and solid, stable and reliable without shaking when mixing;
5. Casters with brake fixed, it is convenient and reliable for mobile use;
6. The PTFE discharge valve without dead corner, solid material/liquid material can be easily released from the bottom;
7. Computer controlled thermostatic oil bath, the intelligent PID control, temperature control is accurate and convenient;
8. Integral structure is scientific design and beautiful appearance, convenient for operation;
9. Explosion-proof series available.
( We can add the cooling coil and an anti-explosion device according to user's needs)

Specification for 1L-5L single layer glass reactor:

Model	LGR-1F	LGR-2F	LGR-3F	LGR-5F
Volume	1L	2L	3L	5L
Glass material	GG-17
Frame material	Stainless steel
Port No. of reactor cover	5
Temperature range	.-80 to 250degree
Vacuum	0.098Mpa
Stirring speed	0-800pm
Stir rod diameter	8mm
Motor power	40W		90W
Heating power	1.5KW		2KW
Voltage	220V/50Hz
Overall size (mm*mm*mm)	320*330*1000		430*330*1200

Specification for 10L-200L single lab glass reactor:

Model	LGR-10F	LGR-20F	LGR-30F		LGR-50F	LGR-100F
Volume	10L	20L	30L		50L	100L
Glass material	GG-17
pot shell material	Spraying antiseptic shell
Pot shell size(mm)	540*440*860	640*540*890	690*590*920		740*640*960	640*640*1200
Inner port material	Stainless steel
Inner port size(mm)	350*220	450*250	500*280		550*320	550*650
Moving mode	Brake type universal corner wheel
Shape of reactor body	Ball type					Cylindrical type
Port No. of reactor cover	7					6
Distance between discharge to floor	450mm
Temperature range	.-80 to 250degree
Vacuum	0.098Mpa
Stirring speed	0-450rpm
Stir rod diameter	15mm

---
