Hot Sales PVC WPC Profile Skirting Board Extruder/Plastic Machinery Extruder of Sjz65/132/Twin-Screw Extrution Machine

Product Description

--- Plastic Conical Twin Screw Extruder ---
---Instruction---
SJSZ series conical twin-screws extruder is one kind of special equipment for all kinds of PVC power extruding and forming. It is equipped with different moulds and auxiliary machines, which
can produce all kinds of PVC Pipes,Profiles,Decorative board,pellets etc.
--- Features ---
Even plastic blending, low shearing rate, high output, stable quality, a wide accommodation, ling service life, advanced design, steady using, cinvenient operation, directly prototyping the PVC powder, matching various molds. The auxiliaries machine can directly process the products like pipes, plates, brs, profile shapes.
1. The barrel and screw adopts cast-aluminum heating rings and air-cooling system. It has the characteristic of quick and fair heat radiation, convenient operation and maintenance and others.
2. The core of screw adopts auto circular cooling regulating system to raise efficiency. According to the different prescription demands of the consumers, the company can make up the most reasonable screw to reach the best plasticizing state and material flow quality.
3. The gearwheel and distribution box adopt famous bearing and imported paint. The gearwheel adopts alloy steel and processed by nitrogen.
4. The temperature-control system adopts imported temperature-control system and imported contactor. The precision of the temperature-control can reach± 10C.
5. Electric motor adopts AC power motor, imported frequency and speed control system, or DC power motor. The electric control system has multiple alarm functions and current protective device.
--- WHY CHOOSE SUKE? ---
(1) We have experiences in this field since 2002
(2) We have strong technical teams and cooperate with China scientific institution to develop, improve and test our machine, to ensure what customers get are the most reliable machines from China.
(3) We select the most reliable mechanical and electrical parts for our machine with all famous reliable brands, with European CE certificated.
(4) We put our heart into every business with aim of long term cooperation.
(5) We have perfect service system-- Our president is devoting himself to pre-sale, on-sale and after-sale service.
--- Believe us, choose us and we will help you succeed! ---

Item of Extruder machine	SJSZ-45	SJSZ-51	SJSZ-65	SJSZ-80	SJSZ-92
Diameter of screw (mm)	45/100	51/105	65/132	80/156	92/188
Number of screw (mm)	2	2	2	2	2
Direction of screw	Screw rotation direction
Screw rotation speed (rpm)	1-37	1-32	1-34.7	1-36.9	1-32.9
Effective length of screw (mm)	985	1070	1440	1800	2500
Power of Main engine (kw)	15	18.5	37	55	90
Barrel heating power (kw)	12	18	24	36	86.8
Production capacity (kg/h)	95	80-120	250-300	320-450	500-600
Center height (mm)	1000	1000	1000	1000	1200
Net weight (kg)	2800	3200	4000	5000	10000
Dimensions (mm) (L*W*H)	3620*1050*2157	3000*1050*2200	4235*1520*2450	4750*1550*2460	6725*1550*2841

--- FAQ ---
1. How can I get the price?
Please provide the details of your requirements as clear as possible. So we can send you the offer for the first time. For designing or further discussion, it is better to contact us by the trademessenger of MIC, WhatsApp, Wechat or other instant messengers, in case of any delays.
2. How can I get a sample to check your quality?
After price confirmation, you can require for samples to check our quality.
Free for the stock sample to check the design and quality, as long as you afford the express freight.
3. What about the lead time for production?
To be honest, it depends on the requirements of the specification.
Generally ---1~2--- months.
4. What are your terms of delivery?
We accept EXW, FOB, CIF, ect.,

---
