US$50,000.00-96,000.00
|
1 unit
(MOQ)
|
Basic Info.
Engine Model
Cummins Isde180 30
Rated Loading Weight (Kg)
9905
Overall Dimensions
8205X2500X2980mm
Refuse Container Capacity (M3)
20
Waste Water Tank (L)
1130
Transport Package
in Nude Package
Production Capacity
500units/Month
Product Description
5250ZYS Compression Garbage Truck Item configure Chassis model DFL1160BX2 Engine model Cummins ISDE180 30 Rated power (kw) 169 Total weight (kg) 25000 Garbage truck weight (kg) 14900,15180,15380,15220 Rated loading weight (kg) 9905,9625,9425,9585 Overall dimensions (LxWxH) (mm) 8205×2500×2980 (around) Max. speed (km/h) 90 feeder nose capacity (m3) 1.3 feeder nose width (mm) 1960 feeder nose height from floor (mm) 180 compressing way Two-way Loading Time(s) (s) ≤24 Unloading Time (s) ≤34 Lifting Time (s) ≤16 Refuse Container Capacity (m3) 20 Waste Water Tank (L) 1130=front 320,430(left,right)+rear380 Compressing thickness (t/m3) ≥0.7 Max. compressing force (kn) 186 Max. thrust/unloading force (kn) 248 Hydraulic system working pressure (Mpa) 21 Cab With A/C
| Dimension mm | 6310×2100×2340 |
| Chassis | NKR77LLPACJAY |
| Engine model | Isuzu 4KH1-TC |
| Max Speed km/h | 95 |
| Container volume m 3 | 6.5 |
| Tailgate hopper capacity m 3 | 0.66 |
| One cycle of pressing s | 13 |
| One cycle of raising s | 10 |
| One cycle of discharging s | 16 |
>>
