Xq6226b Light-Duty Universal Swivel Head Milling Machine Table Swivel

US$4,000.00 1 Piece (MOQ)

Basic Info.

Model NO.
XQ6226B
Structure
Bed type
Milling Cutter Type
Vertical Milling Cutter
Controlling Mode
Program Control
Automatic Grade
Automatic
Precision
High Precision
Certification
GS, CE, ISO 9001
Condition
New
Transport Package
Wooden Box Packaged
Specification
XQ6226B
Trademark
SIECC
Origin
Jiangsu/China
Production Capacity
1000 Sets/Year

Product Description

unit
 XQ6226B
 XQ6226A
 XQ6226-1G
TABLE :



Table size
 mm
 1120X260
 1120X260
 1120X260
T slot
no
 3
 3
 5
Size ( Width )
 mm
 14
 14
 14
Centre distance
 mm
 63
 63
 50
Max. load of Table
 kg
 250
 250
 250
machining range :



table Longitudinal travel(manual/auto)
 mm
 600
 600
 600
table Cross travel (manual/auto)
 mm
 270
 270
 270
table Vertical travel(manual/auto)
 mm
 380
 400
 400
MAIN SPINDLE :



Spindle taper
ISO40
 ISO40
 ISO40
spindle speed /step
 rpm
 45-1660/11steps
 45-1660/11steps
 45-1660/11steps
Max.end milling width
 mm
 125
 125
 125
Max. vertical milling Dia.
 mm
 25
 25
 25
swivel angle of swivel head
 degree
 360º
 360º
 360º
vertical spindle axis to column surface
 mm
 60-500
 60-500
 60-500
vertical spindle nose to table surface
 mm
 100-480
 100-480
 100-480
arm travel
 mm
 440
 440
 440
FEEDS :



Longitudinal/cross feed
 mm / min
 24-402/9steps
 24-402/9steps
 24-720/8steps
Vertical/step
 mm/min
 422/1step

Longitudinal/cross rapid speed
 mm / min
 402
 402
 1040(X)
Rapid Traverse vertical
 mm/min
 422/1step

POWER :



main motor
 kW
 2.2
 2.2
 2.2
(X/Y/Z) feed motor
 kW
 0.37(X/Y),0.55(Z)
 0.37(X/Y)
 0.37(X)
coolant motor
 kW
 0.04
 0.04
 0.04
others



package dimension
 cm
 160X152X222 1pc/case
 160X152X222 1pc/case
 160X152X222 1pc/case


220X152X222 2pcs/case
 220X152X222 2pcs/case
 220X152X222 2pcs/case
overall dimension
 cm
 166x150x173
 166x150x173
 166x150x173
N/W,G/W
 kg
 1480/1680
 1400/1600
 1300/1450
