| US$25,000.00-26,000.00 | 1 Piece (MOQ) |
| SPECIFICATION | SM-250 | |||
| SCREW TYPE | A | B | C | |
| Injection Unit | ||||
| Screw diameter | mm | 50 | 55 | 60 |
| Screw L/D ratio | L/D | 23 | 21 | 19.2 |
| Shot volume(theoretical) | CM3 | 471 | 570 | 678 |
| Injection weight(PS) | g | 428 | 518 | 617 |
| Injection rate | g/s | 180 | 218 | 259 |
| Injection pressure | Bar | 2150 | 1777 | 1493 |
| Screw speed | rpm | 195 | ||
| Clamping Unit | ||||
| Clamping force | KN | 2500 | ||
| Open stroke | mm | 492 | ||
| Space between tie-bars(W*H) | mm | 575*525 | ||
| Max mould height | mm | 580 | ||
| Min mould height | mm | 220 | ||
| Ejector stroke | mm | 150 | ||
| Ejector force | KN | 70 | ||
| Others | ||||
| Max pump pressure | Bar | 16 | ||
| Motor pump power | Kw | 28.7 | ||
| Heating power | Kw | 15 | ||
| Machine dimension(L*W*H) | M | 5.65*1.43*1.81 | ||
| Oil tank cubage | L | 300 | ||
| Machine weight | Ton | 7.3 | ||
| Items | Brand/country | |
| Servo System | Controller | TECHMATION -8' (TAIWAN ) |
| Servo Motor | INOVANCE (CHINA) | |
| Servo Drive | INOVANCE (CHINA) | |
| Oil Pump | ECKERLE (Germany) or SUMITOMO (JAPAN ) | |
| Electric Unit | Stroke transducer | NOVO or FLTCH (Germany) |
| Breaker | Schneider (France ) or LS (Korea ) | |
| Contactor | Schneider (France ) or LS (Korea ) | |
| Air Switch | Schneider (France ) | |
| Location /Speed Sensor | Schneider (France ) | |
| Hydraulic Unit | Hydraulic Direction Valve | YUKEN (Japan) |
| Proportion back-pressure valve | North man (Taiwan) | |
| Plasticizing hydraulic Motor | DAN DUN (ITALY) | |
| Hydraulic Hose | MANULI(ITALY) or GOOD YEAR (USA) | |
| Hydraulic Sealing ring | All Italy and Japan | |
| Others Unit | Mechanical safety | Standard |
| Electric safety | Standard | |
| Mold close fast | Standard | |
| Injection Unit | Linear guide-way | |
| Air core | 1pcs | |
| Hydraulic Core | 1pcs | |
| T slots and screw holes | Standard | |
| Servo system Compared with the other manufacturers is big, Overload ability strong and stable. | ||
