Basic Info.
Model NO.
RTS-D65L161-120Kv
Excitation Mode
Permanent Magnet
Casing Protection
Protection Type
Structure and Working Principle
Brushless
Housing
Black Harden Anodizing Aluminum
Norminal Power
2000W-5000W
Working Voltage Range
6s-20s (25.2-84V)
Cont. Working Current
70A
Transport Package
Carton Package
Packaging & Delivery
Package Size
25.00cm * 20.00cm * 20.00cm
Package Gross Weight
4.000kg
Product Description
Hobiba IP68 Waterproof Sensorless Brushless Motor D65L161 120KV for eFoilProduct DescriptionDear DIY buyers,
Buy 65161 motor from the original manufacturer- Hobiba/Quanly, quality and after-sale service are guaranteed.
Be careful about faked/copied version on the market from Fl***y, who started to copy our motor early 2023.
With an advanced 6-pole and 18 Slots encapsulated core and 65mmdiameter, this series compact DC motors deliver high torque up to15 N*m with maximum output power at 10KW.Thanks to the unique sealing configuration design, these motorsare tested waterproof IP68 according to ingress protection class,and can be operated permanently underwater and applied in dustyenvironments.
1. Working voltage: 60V2. Rated Power: 5000W3. Max Speed: 6400 rpm5. Rated Torque: 10N*m 6. Peak Torque: 15N*m7. Motor Efficiency: >83%
D65L161-WP-Dyno Tester -120Kv
| D65L161 at 120Kv -60V |
| Item No. | C_Voltage
(V) | C_Current
(A) | C_Input Power(W) | M_Voltage
(V) | M_Current
(A) | M_Input Power(W) | M_Efficiency
(%) | M_Speed
(rpm) | M_Torque
(N*m) | M_Output Power
(W) |
| 0 | 59.790001 | 39.540001 | 2364.389893 | 44.220001 | 33.23 | 2309.5 | 89.600266 | 6461 | 2.936004 | 2069.318115 |
| 1 | 59.669998 | 62.650002 | 3736.52002 | 44.139999 | 54.919998 | 3661.679932 | 90.350937 | 6027 | 5.032004 | 3308.362061 |
| 2 | 59.560001 | 85.699997 | 5096.22998 | 44.169998 | 77.959999 | 4981.959961 | 88.756767 | 5655 | 7.168004 | 4421.82666 |
| 3 | 59.439999 | 112.239998 | 6648.189941 | 44.299999 | 105.400002 | 6485.939941 | 83.1203 | 5262 | 9.392004 | 5391.132813 |
| 4 | 59.32 | 138.729996 | 8173.899902 | 44.380001 | 133.539993 | 7945.580078 | 76.354179 | 4906 | 11.336004 | 6066.782715 |
| 5 | 59.200001 | 165.070007 | 9647.320313 | 44.400002 | 160.610001 | 9351.030273 | 68.394165 | 4521 | 12.968004 | 6395.559082 |
| 6 | 59.02 | 217.580002 | 12279.86035 | 44.099998 | 206.119995 | 11840 | 52.375317 | 3804 | 14.944004 | 6201.237305 |
Product Parameters
| Variants | D65L161-125 |
| Winding Turn & Connection | 3T |
| Working Voltage Range | 6-24S(20-100.8V) |
| Max RPM | 12,600 |
| Speed Constant KV(RPM/V) | 125 |
| No-load Current@8.4V without Loading) | 2.0A |
| Torque Constant Kt(N*M/A) | 0.07881 |
| Max Power@max Voltage(KW) | 11.0 |
| Max Torque(N*M) | 15.6 |
| Peak Current(A) | 220 |
| Continuous Working Current (A) | 70 |
| Max Efficiency | 91.0% |
| Weight(kg) | 2.5 |
| Construction | 18N/6P |
| Dimensions (Dimension) | D65*L160 mm |
| Shaft Dimension | D10*30mm |
| Lead wires extension | 8AWGx2m |
| Connection plug (Plug) | 8.0mm plug |
| Working Life | 10,000H |
Customize per your request
Motor drawing- Screw Shaft
Motor Drawing-Splined Shaft
Wiring Diagram
>>
