Plastic Bottle Recycling Equipment

Product Description

Product Description
PET flakes washing recycling line waste pet bottle crushing recycling line
This PET bottle recycling line is mainly used to recycle waste PET bottles to make PET flakes ,mainly inclue de-baling machine, conveyor belt, label remover, sorting system,crushing, floating washing tank, hot washing tank, frication washing, dewatering &hot air drying system, label separator a,with the above machines and process can easily to remove the labels, caps, rings, glue, dirties and other impurities, finally you will produce to clean PET flakes.It can reach achieve request of "Bottle to Bottle" ,"Bottle to Fiber product"
We can make recycling line according to different customize requirements!
Product Parameters
Technical dates

Capacity	Installation power	Area required	Labor required	Water supply
500kg/h	155kwh	35*10*6m	5-6	3t/h
1000kg/h	285kwh	50*12*6m	6-8	4t/h
1500kg/h	350kwh	70*12*6m	6-8	5t/h
2000kg/h	485kwh	80*15*6m	9-10	6t/h
3000kg/h	690kwh	100*18*7m	10-12	7t/h

Detailed Photos
1)Label remover
2)Crushing machine
3)Hot washing machine
4)Cold floating washing tank
5)Dewatering machine
Packaging & Shipping

---
