| US$60.00-75.00 | 200 Sets (MOQ) |
| Model number | MU2493S | MU2493 | |
| Screen | Panel Size (diagonal) | 23.8″ | 23.8″ |
| Panel type | IPS | IPS | |
| Screen size (horizontal/vertical)(mm) | 16:9 | 16:9 | |
| Visible dimension (diagonal)(mm) | 60.5CM | 60.45cm | |
| Border size (border thickness) | 2.1mm | 2.1mm | |
| Black area size (BM area width) | 5.8mm | 5.8mm | |
| Point distance (horizontal/vertical)(mm) | 0.944 (H) ×0.2802(V) | 0.0915×0.2745 mm (H×V) | |
| Screen size (horizontal/vertical)(mm) | 543.744(H)x302.616(V) | 527.04×296.46 mm (H×V) | |
| Brightness (typical value) (cd/m2) | 250cd/m² | 250cd/m² | |
| Contrast ratio (typical value) | 1000:1 | 1000:1 | |
| Response time (typical) | 5ms | 5ms | |
| Viewing Angle (horizontal/vertical)(typical value)(CR≥10) | 178/178(CR≥10) | 178/178(CR≥10) | |
| Scanning frequency | Vertical:60-180Hz | Vertical:48-100Hz | |
| Dot Clock(max) | 97MHz | 96MHz | |
| Maximum resolution | 1920 x 1080 | 1920 x 1080 | |
| Recommended resolution | 1920 x 1080 | 1920 x 1080 | |
| Color support | 16.7M | 16.7M | |
| Color gamut | sRGB 99%(based on 1931) | sRGB 99%(based on 1931) | |
| Anti blue-ray | Yes | Yes | |
| HDR | Yes | NA | |
| Delta E | Factory calibrated ΔE<2 | Factory calibrated ΔE<2 | |
| Connect | HDCP | Yes | Yes |
| Signal input | DP+HDMI+ USB+Audio out+DC | HDMI+VGA | |
| Signal Interface | DP+HDMI+ USB | HDMI1.4+VGA | |
| USB Interface | Yes | NA | |
| 3.5mm audio port | Yes | NA | |
| Loudspeaker box | NA | NA | |
| Powder Supply | Power input | External wall power adapter 12V 3A | External wall power adapter 12V 3A |
| Power consumption (operating mode) | <36W | <30W | |
| Power consumption (Switch-off mode) | <0.5W | <0.5W | |
| External Adapter | Yes | Yes | |
| LED Color (On/Standby) | Blue/Red | Blue/Red | |
| Energy Efficiency Grade | CEL-2 | CEL-1 | |
| POP | NA | NA | |
| Plug and play | VESA DDC2B/CI | VESA DDC2B/CI | |
| User adjustment control | 1. Menu/Confirm selection 2. Switch or exit the signal source 3. Left and right adjustment (add/subtract) 4. Power on and off | 1. Menu/Confirm selection 2. Switch or exit the signal source 3. Left and right adjustment (add/subtract) 4. Power on and off | |
| Language | OSD language | Simplified Chinese and English | Simplified Chinese and English |
| Default language | Simplified Chinese | Simplified Chinese | |
| Loudspeaker | NA | NA | |
| Safety certification | CCC,CEL, | CCC,CEL, | |
| Shell Color | Black | Black | |
| Mechanism function | Wall mounting hole specifications | 100x100mm | 100x100mm |
| Quick base removal | Yes | Yes | |
| Base function | Tilt Angle: -5~15° | Tilt Angle: -5~15° | |
| Product Feature | 1. Ultra-thin bezel-less design 2, no flash screen, software low blue light 3, ultra-low standby power consumption 4, hardware quick disassembly bracket design 5, DC dimming 6. E-book model 7. HDR10 8. Freesync function | 1. Ultra-thin bezel-less design 2, no flash screen, software low blue light 3, ultra-low standby power consumption 4, hardware quick disassembly bracket design 5, DC dimming 6. E-book model | |
| Size | Size (display with base) (Width x height x thickness) | 539.9x385x161mm | 539.9x385x161mm |
| Size (display without base) (L * W * H) | 539.9x320x38.9mm | 539.9x320x38.9mm | |
| Size (carton) (L * W * H) | 620x110x410mm | 620x110x410mm | |
| Weight | Net weight (Kg) | 2.6kg | 2.6kg |
| Gross weight (Kg) | 3.7kg | 3.7kg | |
| Work conditions | Operating temp range | 0ºC~50ºC | 0ºC~50ºC |
| Operation humidity | 5%~90% (Non-condensation) | 5%~90% (Non-condensation) | |
| Operating height | ≤2000m | ≤2000m | |
| Storage condition | Storage temperature range | -20ºC~60ºC | -20ºC~60ºC |
| Storage humidity | 5%~90% (Non-condensation) | 5%~90% (Non-condensation) | |
| Storage height | ≤2000m | ≤2000m | |
| Loading | 40' HQ | TBD | TBD |
| 40' Standard | TBD | TBD | |
| 20' 'Standard | TBD | TBD | |
| Accessory | Display (bracket/base) + adapter *1+ Signal cable DP*1+QSG*1(for reference only) | Display (bracket/base) + adapter *1+ Signal cable DP*1+QSG*1(for reference only) | |
