Heavy-Duty 3000lbs Permanent Magnetic Lifter for Industrial Use

US$105.12
30-99 Pieces
US$94.53
100-199 Pieces
US$88.25
200+ Pieces

Basic Info.

Model NO.
3 ton
Type
Safety Hook
Material
Steel
Lifting Capacity
3T
Fixed Form
Bolt Type
Lifting Eye Type
Flat Eye
Rope Core Type
Steel Core
Power Source
Electric
Shape
Round
Certification
GS, CE, ISO 9001
Sling Color
Yellow
Core Components
Electromagnetic Chuck
Application
Industrial Magnet
Usage
Lifting Steel Scrap
Feature
High Frequency
Composite
Magnetic Wire
Cold State Power
5.85kw
Conductor Coil
Aluminum or Copper
Dimension
900*1090*200mm
Transport Package
Wooden Case
Specification
0.1-30ton
Trademark
Huiyu
Origin
Hebei, China
HS Code
8505901000
Production Capacity
3000 Peices/Month

Product Description

Crane electromagnetic chucks, also known as magnetic chuck and crane electromagnets, are mainly used for lifting magnetic materials such as steel in metallurgy, mining, machinery, transportation and other industries. Also it is used as an electromagnetic manipulator to clamp magnetic materials, and suitable for handling cast iron ingots, steel balls and various scrap steel. The excitation mode can be constant voltage mode, strong excitation mode and over excitation mode.
FEATURE & ADVANTAGE Crane electromagnetic chuck adopts fully enclosed structure and has good moisture resistance. Our crane electromagnetic is optimized by computer, the structure is reasonable, and the energy consumption is low. The excitation coil is treated by special process to improve the electrical and mechanical properties. The insulation material has a heat resistance grade of C and a long service life. Different structures and parameters are adopted for different items to be sucked, which can widely meet user requirements. The high-temperature electromagnet adopts a unique heat insulation method, the sucked material temperature from former 600 ºC to present 700 ºC, expanding the applicable scope of the electromagnet. Easy installation, operation and maintenance. PRECAUTIONS FOR USE Check whether the parts of the electromagnetic chuck are damaged before use, and replace them timely. Pay attention to the surroundings before lifting, and do not pass from the top of equipment and personnel Check whether the rated current is reached before lifting. Pay attention to the inspection before lifting, whether there is non-magnetic material between the lifting object and the lifting electromagnetic chuck, so as not to affect the lifting height. Crane electromagnet Cold-state power(kw):2.6-41.6 Lifting capacity: 500kg-40000kg Color: yellow/orange Rated voltage: according to client's requirement We can make products according to customer requirements.
Rated Capacity Cylindrical Capacity Max Tear-off strength Length Width Height Handle N.W
(Kg) (Kg) (Kgf) (mm) (mm) (mm) (mm) (Kg)
100 30 350 92 64 70 142 3
300 100 1050 165 88 96 176 10
500 150 1750 216 118 120 219 20
600 200 2100 236 118 120 219 24
1000 300 3500 264 168 168 266 50
1500 500 5200 353 172 168 380 70
2000 600 7000 378 230 217 462 125
3000 1000 10500 453 290 265 567 220
5000 1500 17500 647 290 265 707 355
6000 2000 19200 713 290 265 707 398
