Purpose:
This test is to determine the ability of the module to withstand wind , snow , static or ice loads
Technical specifications:
1、The machine table appearance dimension:L 280 × D 180 × H 195 cm
2、Test Positive load 5400Pa, reverse load :2400Pa (Pressure can setting)
3、Cycle times :free setting
4、Dynamic load test frequency:7s±3s
5、Dynamic load:1000Pa，1000tims
6、Pressure control accurate:5%
7、Pneumatic and force value feedback ways :low friction force cylinder,tensile pressure
sensor(accurate 0.1N)
8、Aluminum profile structure feature:platform and support frame aren’t deformation under the suffer force situation
9、The maximum test dimension:2000mm×1000mm (can according to customer’s requirement to customized)
10、Customization test platform fixture, according to determinand install ways to do the adjust
11、Current continuity system :DC power, DC 150V/2A, real-time monitor module inner current continuity
12、Cylinder: 4 groups , in total 8 pieces
Single the maximum output > 200 kg
Telescopic stroke:125mm
13、Sucker:8 groups , in total 32 pieces
Sucker diameter:120mm
Sucker(with cylinder) space horizontal and vertical≤200mm
Sucker can rotation angle ≥15°
14、Operate system
14.1、Computer control software research and development by HOTOTECH , easy operate and stability
14.2、Software with Chinese and English language , can change each other
14.3、real-time show pressure, deformation, test time, cycle times , current continuity
14.4、Real-time draw and show pressure and deformation value
14.5、Real-time show every cylinder force value and draw force value curve
14.6、Testing data real-time save, inquiry and print
14.7、Testing data export is World, Excel, PDF , JPG etc format
14.8、Fault alarm function
6 industry advanced technologies
Shunyang SOLAR have introduced advanced equipment and leading technology in the industry with high standards, integrated low temperature anhydrous nondestructive slicing technology, large scale silicon wafer, multi bus bar， half-cut, dual glass，bifacial power, micro gap welding, Structural ribbonand so on，representing the first-class technical level and manufacturing process in the industry，ensures that the efficiency, performance and reliability of our products reach the industry-leading level.
The largest capacity of single line production in China
The designed capacity of our single production line reaches 1GW, which is twice the average level.
Industry's highest compatibility of product
The production line can be compatible with the single / dual glass photovoltaic modules of the most advanced PERC cells, N-type TOPCON cells and HIT cells , as well as the green building materials production of BIPV.More than 70 compatible product categories.
The most comprehensive application of AI quality control
Five quality control procedures are designed on the whole production path of a series of inspection including IQC-IPQC-OQC to realize AI aided judgment, big data collection & analysis and industrial cloud technology aided storage & control, so as to ensure the product quality.
25 years of PV manufacturing experience Long-term and stable cooperation of supply chain
With Yingli group’s first mover advantage and layout of deep cultivation in the global photovoltaic field, Shunyang SOLAR has established a long-term and stable cooperative relationship with the upstream and downstream of the supply chain to ensure the long-term stability and reliability of the quality of various materials required for modules. At present, our high-efficiency photovoltaic modules have been unanimously recognized by major customers at home and abroad, and we have established cooperative relationship with Sinopec, CGN, Beijing Jingneng, Guokai New Energy, State Grid Comprehensive Energy, State Power Investment, CNNC China Huaneng and other high-quality enterprises. Promoting the green and low-carbon transformation.
3 systems throughout the whole chain QC system·Distribution system·Quality tracking system
Based on the quality strategy, making efforts to build the brand of Shunyang SOLAR and service system, focus on internal and external circulation, comprehensively promote the upgrading of product and service quality, Quality wins the future of zero-carbon!
