| Figure NO: | Description | QTY.(piece) |
| Figure 1 | Test Pin with 5N force | 1 |
| Figure 2a.2b | Apparatus for mechanical strength test on resilient covers | 1 |
| Figure 5 | Gauge for plug pins | 1 |
| Figure 6 | Apparatus for testing plug cover fixing screws | 1 |
| Figure 7 | Mounting plate | 1 |
| Figure8 | Plug pin deflection test apparatus for resilient plugs | 1 |
| Figure 10 | Apparatus for pressure test at high temperatures | 1 |
| Figure 11 max/min | GO gauge for socket-outlet | 2 |
| Figure 12 | Contact test gauge | 1 |
| Figure 14 | Noncontact test gauge | 1 |
| Figure 15 | Turning moment gauge | 1 |
| Figure 16a.16b | withdrawal pull gauge for effectiveness of contact | 2 |
| Figure 17a/17b | Test apparatus for temperature rise test and the dummy front plate | 1 |
| Figure 19 | Solid link for test on fuse clips | 1 |
| Figure 23 | Apparatus for pressure test | 1 |
| Figure 29 | Calibration of calibrated link | 1 |
| Figure 30 | Test plug for temperature rise | 1 |
