| Display Pane | Brand | TKUN |
| Size/Proportion | 13.3 inch 16:9 | |
| Model | P133CCHS | |
| Brightness | 450cd/㎡ Can be customized 1000cd/㎡ | |
| Resolution | 1920*1080 | |
| Contrast | 1000:1 | |
| Display color | 16.7M | |
| Response time | 2-5ms | |
| Visible angle | 85/85/85/85(Typ.CR≥10) | |
| Pixel pitch | 0.153(H)X 0.153(V)mm | |
| Draw quality | 3D noise reduction, high-definition signal, progressive scan | |
| Touch Function | Touch screen | Capacitive touch screen (10 points) |
| Surface hardness | ≥6h | |
| Transmittance | ＞95% | |
| Positioning accuracy | less than 2mm | |
| Click lifetime | > 60 million times | |
| Touch medium | Current sensing, capacitive touch pen, finger | |
| Right-click function | click on a certain point and press for more than 3 seconds | |
| Touch interface | USB | |
| Motherboard Function | Mainboard | TKUN industrial motherboard |
| CPU | Intel Celeron J6412 Quad-core | |
| the cpu frequency is 2.0ghz， Speed Up to 2.6GHz | ||
| Secondary cache 1.5 MB L2 Cache | ||
| integrated graphics | Intel® UHD Graphics for 10th Gen Intel® Processors | |
| graphics frequency | 400MHz | |
| dynamic frequency | 800MHz | |
| System | Windows 10 IoT Enterprise（support Windows11，Linux，UOS） | |
| RAM | 4G (optional 8G/16G/32G) | |
| SSD | 128G(optional 256G/512G/1T/2T) | |
| LAN | LAN*2 Intel® 10M/100M/1000M/2.5Gbps adaptive | |
| USB | USB3.0*4 | |
| COM | RS232(485)*4 （customizable RS422） | |
| HDMI | HDMI*1 | |
| SIM | SIM*1 | |
| Extensible | 4 expansion interfaces,(interface type USB，COM, GPIO) | |
| Wireless Network | Wireless card | Wifi is not available as standard (optional) |
| Open Close | Power | Power*1 (power-on and power-on function can be set) |
| Power Input | AC/DC | DC9-36V |
| Watchdog | Watch dog timer | 0-255 seconds, providing watchdog routine |
| Product Power | Power | ≤20W |
| Environment | Operating temperature/humidity | -10℃ to +60℃/ 0-80% relative humidity, no condensation |
| Storage temperature/humidity | -15℃ to +65℃/0-90% relative humidity, no condensation | |
| Vibration resistant | 30Hz, X, Y, Z axis 60 minutes each | |
| Esd protection | Class 3, contact discharge ± 6KV, air discharge ±8KV | |
| Panel level | IK6 | |
| Test standards | IEC60601 | |
| Product Service | After service | one-year warranty and lifelong maintenance |
| Customized service | OEM/ODM is available for material, appearance, dimensions, wide temperature, outdoor highlight, wide voltage, etc. |
