High Capacity of Scrap Iron Lifting Magnet for Scraps

Product Description

Product Description
Oval Shape Magnetic lifter is suitable for lifting steel scraps in box-shaped cart.
Features:
1.Oval shape is suitable for using in Carriage shape,efficiently handle scraps.
2.With deep magnetic field and strong magnetic force,it can handle substantial scraps at a time.
Product Parameters

Model	Electric current (A)	Cold-state power (kw)	lifting capacity (kg) cold/hot state		Mass (kg)	Overall dimension (mm)
			cast iron	steel scrap		A	B	C	D	E	F
MW61-180160L/1-75	113/78	32.7/15.5	2550/2000	1150/900	5000	1800	1600	1500	310	210	60
MW61-200150L/1-75	110/76	31.9/15.2	2200/1900	1000/800	4200	2000	1500	1300	250	180	70
MW61-200180L/1-75	142/108	41.2/23.8	2300/1900	1100/900	4500	2000	1800	1400	400	240	70
MW61-250150L/1-75	198/150	57.4/33	4000/3000	2000/1600	5000	2500	1500	1700	300	210	60
MW61-250180L/1-75	238/181	69.02/39.82	4500/3000	2200/1600	9000	2500	1800	1700	180	110	55
MW61-250200L/1-75	179/123	51.9/24.5	5000/4200	2500/1800	8400	2500	2000	2000	390	280	80
MW61-300150L/1-75	195/135	56.6/27	2400/2850	1500/1250	5700	3000	1500	1570	310	210	60
MW61-300180L/1-75	198.6/150	57.6/33	3500/2850	1600/1300	7500	3000	1800	1570	400	250	80
MW61-300200L/1-75	207/157.1	60/34.5	4000/3500	2500/2000	10500	3000	2000	1800	400	250	80
MW61-350220L/1-75	254.4/193	73.8/42.5	7000/6000	3500/3000	12000	3500	2200	1955	400	300	80
MW61-360180L/1-75	240/180	69.6/39.6	5000/3500	2500/2000	11000	3600	1800	1955	400	250	80
MW61-400150L/1-75	182/138	52.8/30.4	4000/3500	2500/2000	8500	4000	1500	2350	410	260	80

Complete set of Equipment:
· Magnetic Lifter
· Spring type cable reel with cable
· Rectifier control cabinet (Normal type,Strong excitation type, Battery back-up type)
· Cable connector / Quick coupling
About Enquiry:
To help you get the best electro lifting magnet for your application, we should have the following information:
1. What are the materials you want to lift?
Steel scraps, steel billet, ingot, plate, bar or ball. For steel plate, please let us know its dimension (Length× Width× Thickness mm)
2. What's the lifting capacity you expect?
3. What kind of working site does the magnet work? Indoor or outdoor?
4. Kindly provide your power supply information (__V, DC/AC,__Hz), and information for crane (single beam or double beam, single hook or double hook, how about its loading capacity).
5.Do you need full set with cable reel, control cabinet or only magnet?
6.Do you need FOB or CIF price, which port?
(More details, please feel free to contact us directly. )
Application
Company Profile
Certifications
FAQ
1. Why customers choose us?
We are a professional lifting magnet products manufacturer with 18 years experience in China.We have our own factory which can offer better price, control delivery time better based on strict quality inspection and good after-service guarantee.
2.What is your payment terms?
Our payment is 30% T/T deposit,70% balance before factory delivery.
3.How long is your delivery time?
A:Standard model is within 10 workdays after deposit confirmed.
Customerized model will depend on actual production needs.
4.What is the total cost of freight?
Please provide your port of destination in order to give accurate freight.
5.Can I have product with our design and nameplate?
Of course,we welcome OEM and ODM order. Our engineer will provide you the proposal based on your detailed requirements.
6.What is your warranty and after service?
Our product is with 12 months warranty from delivery. We also support engineer to oversea market. Frankly speaking,with equipment renovation technology, our products tend to free maintenance.

---
