CH Horizontal Trough Type Single Blade Mixing Trough Mixer

Product Description

Main application:
This machine is used for mixing the powdery or pastel supplies, making the material of different qualities, its characteristic is that the type of mix is horizontal groove-type thick liquid, mix thick liquid as coherent axle, easy to wash. The parts contacting with the material are all made of stainless steel.

Operating principle:
Use the rotation of the thick liquid leaf in the material groove to mix different qualities material evenly. Round groove mixer material groove and thick liquid leaf turn round backward at the same time, the efficiency of the groove-type mixer than general type and more even it can mix.

Technique parameter:

Model	CH-50
Working volume(l)	50
Main arm speed(min)	24
Mixing cycle/ (min)	5-20
Main motor(kw)	1.1
Dumping motor(kw)	0.75
Net weight(kg)	280
Overall size(mm)	980 x 420 x 800

Production Press
Exhibition Room
Factory
Certificate
Our Services
Pre-sale service
1. Help clients to choose the most suitable machine
2. Supply detailed machine instruction,principle of operation
3.Produce the machine according to clients' requirement

After-sale service
1. One year warranty
2. 24 hours online to solve any problem; supply you English manual book and technical support, maintain and install video to help you solve the problem, or dispatch worker to your factory.
FAQ
Q1: What is the warranty for this machine?
A1: 1 year.
Q2: Do you offer oversea installation?
A2: We'll send professional installation engineer to help you install the equipment, and train the operators. But the buyers must take the charge of round trip air ticket and accommodation. Also your should pay engineer $80 per day.
Q3: How long is the lead time?
A3: Generally 25 working days, for special orders, please contact sales manager for confirmation.
Q4: What's the terms of delivery?
A4: Shipping and Air Express as DHL, FedEx, TNT, UPS, EMS, for details, please contact sales manager.
Q5:What's the terms of payment?
A5: TT, L/C.

---
