Engine
|
Engine Displacement
| 47cc
|
Engine type
| 49CC,Air-cooled, Single cyclinder, 2-stroke
|
Max Power
| 2kw/700rpm
|
Max.torque and rotate speed
| 3.5N.m / 6,000RPM
|
Starter
| Alloy Easy Pull Start / Button Electric start
|
Dimensions and Weight
|
Length x Width x Height
| 1,060x600x670mm--4" tire / 1,030×660×710mm-6" tire
|
Wheelbase
| 710mm
|
Ground clearance
| 140mm
|
Fuel Capacity
| 1litres
|
Fuel/Oil Ratio
| 25:1
|
Fuel consumption
| 100km/2.4L (Note: According to the terrain conditions & loading weight)
|
Wheels, Suspension and Brakes
|
Wheels(F/R)
| Steel rim
|
Product Material:
| Steel frames + ABS Plastic deck
|
Tyre material
| Rubber,with inner tyres
|
Tyres(F/R)
| 4.10-4/4.10-4 OR 4.10-6/13X5.00-6
|
Shock Absorber Front
| Adjustable Shock
|
Shock Absorber Rear
| Adjustable Shock
|
Final Drive
| Chain
|
Brakes(F/R)
| Disc / Disc
|
Max load capacity
| 110KG
|
Max speed
| 45km/h
|
Packing
|
Carton Size
| 990x570x510mm
|
G.W./N.W.
| 34/38KG
|
Container Load
| Qty/20Fcl:110pcs / Qty/40HQ:230pcs
|
