Welcome to visit

PP Single Screw Water Cooling Rotary Die Double Rewinder Film Extrusion Machine

US$15,000.00-50,000.00 1 Set (MOQ)

Basic Info.

Type
PE Film Blowing Machine
Raw Material
PP
Maximum Folding Width of Film
600mm
Screw Diameter
55mm
Automation
Non-Automatic
Computerized
Non-Computerized
Machine Weight
4T
Certification
CE
Speed
High Speed
Die
Rotary Die
Rewinder
Single or Double
Transport Package
Stretch Film Packaging, Wooden Case
Specification
5.5m*2.1m*4.7m
Trademark
RILI
Origin
Made in China
HS Code
8477209000
Production Capacity
50 Sets/ Year

Product Description

PP Single Screw Water Cooling Rotary Die Double Rewinder Film Extrusion Machine Main Uses and Characteristics:
1.It is suitable for producing polypropylene packing bags of various sizes(such as packing bags for clothing, food, textile and industrial products, etc.)
2.The cylinder and the screw stem of the extruder are made of high-quality alloy steel after nitrogen treatment, which has the best hardness and corrosion resistance.
Main Technical Variables:
Model RL-P-55 RL-P-60 RL-P-65
Screw Diameter 55mm 60mm 65mm
Screw Ratio L/D27:1 L/D27:1 L/D27:1
Screw Speed 10-100r/min 10-100r/min 10-100r/min
Power of Main Motor 15Kw 18.5Kw 22Kw
Rotational Mode of Machine Head Continuous rotation Continuous rotation Continuous rotation
Main Output 32kg/h 38kg/h 42kg/h
Max Folding Width of Film 600mm 700mm 800mm
Single-sided Thickness of Film 0.01-0.10mm 0.01-0.10mm 0.01-0.10mm
Weight of Machine 2300kg 2900kg 3500kg
Overall Dimensions 4800×2500×4000mm 4800×2500×4200mm 5000×2500×4500mm

Machine Pictures:
Machine Loading
